Keysight U1620A 200 MHz Bandwidth Digital Handheld Oscilloscope with 2 Floating Inputs and 2 MegaPoints Memory Depth
Keysight U1620A 200 MHz Bandwidth Digital Handheld Oscilloscope with 2 Floating Inputs and 2 MegaPoints Memory Depth
Keysight U1620A 200 MHz Bandwidth Digital Handheld Oscilloscope with 2 Floating Inputs and 2 MegaPoints Memory Depth
Keysight U1620A 200 MHz Bandwidth Digital Handheld Oscilloscope with 2 Floating Inputs and 2 MegaPoints Memory Depth
Keysight U1620A 200 MHz Bandwidth Digital Handheld Oscilloscope with 2 Floating Inputs and 2 MegaPoints Memory Depth
Keysight U1620A 200 MHz Bandwidth Digital Handheld Oscilloscope with 2 Floating Inputs and 2 MegaPoints Memory Depth
Keysight U1620A 200 MHz Bandwidth Digital Handheld Oscilloscope with 2 Floating Inputs and 2 MegaPoints Memory Depth
Keysight U1620A 200 MHz Bandwidth Digital Handheld Oscilloscope with 2 Floating Inputs and 2 MegaPoints Memory Depth
Specifications
Brand Name :
Keysight
Model Number :
U1620A
Certification :
CE
Place of Origin :
Malaysia
MOQ :
1 Piece
Price :
Negotiation
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
In Stock
Delivery Time :
1~3 Working Days
Packaging Details :
Carton
Product Name :
Power Sensor
Frequency range :
200Mhz
Power measurements :
-50 dBm to +30 dBm
Condition :
Pre-Owned
Functions :
Tested, in Full Working Conditions
Form Factor :
Plug-In
Description
Keysight U1620A Service Oscilloscope, 200 MHz, 2-Channel, Floating Instrument
Product Overview

The Keysight U1620A is a 2-channel digital handheld oscilloscope with 200MHz bandwidth, 2 MegaPoints memory depth, VGA color display, and potential-free inputs. This floating instrument offers exceptional performance for service and field applications.

Key Features
  • Bandwidth: 200 MHz
  • 2 floating inputs with 600 V CAT III channel to channel separation
  • Storage depth: 2 megapoints
  • Sampling rate: 2 GSa/s
  • Vertical resolution: 8 bits
  • Vertical sensitivity: 2 mV/div to 50 V/div
  • Trigger system: normal, single, auto
  • Trigger types: Edge, Glitch, TV, Nth Edge, CAN, LIN
  • 30 automatic measurement functions including delay, duty cycle, rise/fall time, frequency, period, and more
  • Math functions and FFT analysis (1024 points)
  • Brilliant 14.5 cm VGA color display with wide viewing angle
  • 3 selectable views (indoor, outdoor, and night view)
  • Built-in multimeter and data logger
  • Multimeter functions: voltage DC/AC, current AC/DC, resistance, capacitance, continuity, diode, temperature, frequency
  • 10 selectable languages for operation
  • Built-in help system
  • Storage option: 10 setups and signal data
  • Interfaces: USB 2.0 full-speed host and client
  • Dimensions: 183 x 270 x 65 mm (W x H x D)
  • Weight: <2.5 kg
Technical Specifications
Article number: U1620A
Bandwidth (MHz): 200
Counter: No
DVM: Yes
Dimensions (L x W x H) (mm): 65 x 183 x 270
Function generator: No
Interfaces: USB
Model: U1620A
