Keysight Agilent N4001A SNS Series Noise Source 10 MHz to 18 GHz ENR 15 dB

Product Overview

The Keysight Agilent N4001A is a Smart Noise Source (SNS) from the SNS Series, covering 10 MHz to 18 GHz with a nominal ENR of 15 dB. Designed for use with Keysight NFA Series noise figure analyzers and PSA/ESA/MXA/PXA spectrum analyzers with noise figure measurement capability, this SNS noise source provides electronic storage of ENR calibration data, eliminating the need for manual ENR table entry and reducing setup errors. This unit is pre-owned, fully tested, and can be ISO 17025 calibrated with a data certificate upon request.

Key Features & Specifications

• Frequency Range: 10 MHz to 18 GHz
• ENR (Excess Noise Ratio): 15 dB nominal
• Connector Type: 3.5 mm male
• SNS Smart Technology: Electronic ENR data storage for automatic upload to analyzer
• Compatible Analyzers: NFA Series noise figure analyzers, PXA/MXA/EXA/ESA/PSA spectrum analyzers with noise figure option
• SWR: Low VSWR for improved measurement accuracy
• Condition: Pre-Owned, tested in full working condition

ISO 17025 Calibration

This N4001A can be ISO 17025 accredited laboratory calibrated with a full data certificate including:

• ✅ ENR values at multiple frequency points (with measurement uncertainty)
• ✅ Complete calibration data traceable to national standards
• ✅ Accredited calibration certificate with measurement results
• ✅ Calibration performed before shipment

Applications

• Noise figure measurement of amplifiers, mixers, and receivers
• Noise parameter characterization of LNAs and RF front-ends
• Production testing of wireless communication components
• R&D characterization of low-noise RF and microwave devices
• Satellite communication and radar system testing
