TNC Male Crimp Type Plug Connector RF Coaxial Cable for RG58 RG223 RG316
TNC series connectors feature a screw-coupling design similar to BNC connectors, operating at 50 ohms impedance. These connectors offer wide frequency bandwidth, convenient connection, vibration resistance, and reliable electrical and mechanical performance. They are particularly suitable for computer networks, electrical instruments, and microwave systems including TV microwave stations, mobile phones, aerospace, navigation, and radar surveillance applications.
Key Features
  • Screw-coupling design for secure connections
  • 50 ohms impedance rating
  • Wide frequency bandwidth (DC-11GHz)
  • Vibration-resistant construction
  • IP67 waterproof sealing
  • Reliable electrical and mechanical performance
Specifications
Application RF Type TNC
Contact Material Brass Housing Material Brass
Gender Male Plating Ni
Frequency Range 0-3GHz IP Level IP67
Model Number TNC-C-J3 Impedance 50Ω
Environmental Conditions
Temperature Range -55°C to +155°C
Frequency Range DC-11GHz
Working Voltage 500V r.m.s at sea level
Vibration 150m/s² (10-500Hz), 10g
Salt Spray Test 5% NaCl solution; test time ≥48h
Waterproof Sealing IP67
Technical Characteristics
Withstanding Voltage 1500V r.m.s at sea level
Contact Resistance
Center Contact ≤10mΩ
Outer Contact ≤2.5mΩ
Insulation Resistance ≥5000MΩ
Center Contact Retention Force ≥0.57N
Coupling Nut Retention Force ≤20N
Insertion Loss 0.2dB/6GHz
Voltage Standing Wave Ratio
Straight ≤1.22/3GHz
Right Angle ≤1.30/3GHz
Shielding Efficiency ≥60dB/3GHz
Disengagement Force ≤445N
Durability (matings) ≥500 cycles
Average Power ≤0.50kW
Packaging Information
Selling Units Single item
Package Dimensions 1×1×1 cm
Package Weight 0.010 kg
