J30J Series Connector 21pins Male Plug Center Contact Gold Plating with White Wire 500mm for Sensor
J30J Series Connector 21pins Male Plug Center Contact Gold Plating with White Wire 500mm for Sensor
Specifications
Brand Name :
ELT
Model Number :
J30J-21TJL-500
Certification :
ISO Certificates
Place of Origin :
Xi'an, China
MOQ :
In stock
Price :
Depending on the quantity
Payment Terms :
T/T or LC
Supply Ability :
As requirements
Delivery Time :
5-10 working days for stocked quantity
Packaging Details :
Carton
Contact Termination :
Crimp
Center Conductor :
Copper Alloy, Gold Plating
Outer Conductor :
Aluminum Alloy, Nickle Plating
DWV :
800V
Insulation Resistance :
≥5000MΩ
Contact/Pin :
21 pins
Mating Cable :
AFR-250, White Wire 0.10mm2
Wire Length :
200mm, 300mm, 500mm, 1000mm
Operating Temp :
-55℃~+125℃
Storage Temp. :
-55℃~+125℃
Product Name :
J30J Series Connectors
Insulation Dielectric :
PBT
Description

Product Description:

J30J Series Connectors ( also called Micro-D connectors ) represent a miniaturized evolution of standard D-subminiature connectors. Their core advantages lie in an extremely compact footprint (with a pin pitch of only 1.27mm) and a lightweight design, all while maintaining superior electrical performance and mechanical robustness. This ensures stable connections even under extreme conditions involving vibration, shock, and temperature fluctuations.

Features:
  • High Density Design:
  • Integrates more signal contacts within limited space, supporting various pin configurations including 9, 15, 21, 31, and 51 positions.
  • Ultimate Reliability:
  • Features gold-plated contacts and an aluminum alloy shell, providing excellent Electromagnetic Interference (EMI) resistance and corrosion resistance.
  • Application:
  • Perfectly suited for satellite communications, radar systems, telemetry & control systems, and high-end industrial instrumentation.

Technical Data:

Outline Dimension of J30J Series Connector 21 pins Male Plug:


Product Model J30J-21TJL-500 (21pins, male plug, wire length 500mm)
Technical Materials & Finish
Impedance / Center Conductor Copper Alloy, Gold Plating
DWV 800V Outer Conductor Aluminum Alloy, Nickle Plating
Insulation Resistance >5000MΩ Insulation Dielectric PBT
Temperature Operating Temp.: -55℃~+125℃ Storage Temp.: -55℃~+125℃



J30J Series Connector 21pins Male Plug Center Contact Gold Plating with White Wire 500mm for Sensor

Applications:

The J30J Series connector's operating temperature range of -55℃ to +125℃ makes it suitable for use in harsh environmental conditions.

Thanks to its contact termination via crimp, the J30J Series Connector guarantees secure and durable connections. With a supply ability tailored to meet specific requirements, this product is well-suited for a wide array of industries and applications, including but not limited to aerospace, aviation, navigation, satalite, radar , telecommunications, electronics and industrial automation.


Customization:

Customize your J30J Series Connector with Elite Electronic 's Product Customization Services:


We also can customize the special pins such as the 12 pins, 24 pins, 35pins, 39 pins, 41 pins, we will arrange the project evaluation by our engineer before the customization.

Packing and Shipping:


  • Packaging:


The J30J Series Connector is securely packed in a durable cardboard box to prevent damage during shipping.

  • Shipping:


We use fedex, DHL or air shipment to ensure safe and timely delivery of your J30J Series Connector.
