Micro Rectangle MDM D Sub 9 Pins Connector Hermetic Sockets
Micro Rectangle MDM D Sub 9 Pins Connector Hermetic Sockets
Micro Rectangle MDM D Sub 9 Pins Connector Hermetic Sockets
Micro Rectangle MDM D Sub 9 Pins Connector Hermetic Sockets
Specifications
Brand Name :
ELT
Model Number :
J50J-9TJ-1
Certification :
CE, ROHS
Place of Origin :
China
MOQ :
5pcs
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
35000pcs/year
Delivery Time :
Within in 3 weeks
Packaging Details :
Standard Export Carton
Out Shell :
aluminum alloy
Contact Pin :
9 pins
Material :
Metal
Section area :
0.15-0.3 mm²
Contact Spacing :
1.91 mm
Standard :
MIL-DTL-83513
Contact type :
micro twist pin, gold plating
Product name :
J50J,Mirco-D, D-sub, MDM
Ceritification :
ROHS ISO-9001-2015
Leak Rate :
≤1.01X10^-3 Pa.cm^3/s
Description

J50J Hermiticlly D-sub Socket

J50J Series is a metal shell product with 1.91mm contact spacing, 1.65mm row spacing, the cross-sectional area of wire is 0.15-0.3mm² and the number of contacts: 9, 15, 21, 25, 31, 37, 51 and 66 contacts.
Termination type include crimping, soldering, straight PCB and right angle PCB,etc.
The product has the advantages of high density, light weight and miniaturization.
It can realize the reliable interconnection of the electrical circuit system between the internal cables to cables, cables to PCB, PCB to PCB.

Contact Arrangements
(Face View of Pin insert)

Micro Rectangle MDM D Sub 9 Pins Connector Hermetic Sockets

Specification:

Micro Rectangle MDM D Sub 9 Pins Connector Hermetic SocketsMicro Rectangle MDM D Sub 9 Pins Connector Hermetic SocketsMicro Rectangle MDM D Sub 9 Pins Connector Hermetic Sockets

Current Rating 5A
Voltage Rating 300V
Insulation Resistance ≥ 5000 MΩ
Durability 500 cycles
Dielectric Withstand Voltage 1000V
Environmental Temperature -55℃ ~ + 125℃
Relative Humidity +40℃ up to 95%
Vibration 10Hz~ 2000Hz 196m/S²
Impact 980m/S²

Outer Dimension Drawing

Micro Rectangle MDM D Sub 9 Pins Connector Hermetic Sockets

Types:

- J30J series
- J30JM( Hermetic) series
- J30(Plastic) series
- J50J series
- J55A series
- J55AM( Hermetic) series
- J56J series
Applications:

- Avionics, radars
- On-board equipment
- Telecommunication systems

- Research centres

- GPS

- UAV

- Communications

- Satcom

- Navigation systems
- Research centres
- Medical applications
- Surface Mount (SMT) Board to Cable
