Dual Bed Deionizers by ion exchange purification water filters 200,000 to 800,000 grains

Engineered for large-sized deionization (DI) applications, these dependable units feature precise electronics and performance characteristics, using diaphragm valves package. Applications cover the full spectrum of industrial, medical, electronics manufacturing, boiler feed water, and chemical manufacturing uses. We are able to supply a full line of standard and fully customizable dual bed deionizer systems, all of which are engineered using advanced computer modeling and process design software for accurate and customized solutions.

Advantages Of A Dual Bed Deionizers DB-X Series

• Two-Bed Automatic “Package” Deionizers are available in sizes from 11-43 GPM, and at rated exchange capacities of 200,000 to 800,000 grains. These systems are fully-assembled, with all wiring and tubing completed requiring minimum installation and start-up effort. Skid mounting is an option.
• Exchanger's vessels are all nonmetallic construction, rated at 150 psi.
• Piping is Schedule 80 PVC, with solvent-welded joints, rigidly supported on unit strut channels.
• Valves-Noryl diaphragm type, pneumatically operated, with integral travel, stops for flow regulation.
• Internal distributions are PP/schedule 80 PVC and radial lateral design.
• The provided cation resin is a high capacity strong acid, bead-form, conventional gel polystyrene sulfonated exchange resin which is shipped in the hydrogen form ready for immediate use. Resin capacity information is based on 6 lbs. of HCL per cu. ft. of exchange resin. The provided anion is a high capacity strong base, type 2, bead form, conventional gel exchange resin which is shipped in the chloride form for maximum storage life. Resin capacity information is based on 6 lbs. of NaOH per cu. ft. of exchange resin.
• Optional stainless steel liquid filled pressure gauges, sample valves, flow indicator on water inlet, and inlet pressure reducing valve.
