Features
Product Specifications
P/N | LED | CCT | CRI | LED | LUMENS | VIN | Current | Power | Cut Length | Max Run |
RL-FV2422024283520-830-WWTH2515 | 2835 | 2700 | 80/90 | 24 | 1660 | 24 | 833 | 20 | 125 | 5 |
3000 | 1660 | |||||||||
4000 | 1700 | |||||||||
6500 | 1700 | |||||||||
RL-FV2422024505015-DMX-WWTH2515 | 5050 | R:620-630 | 80/90 | 24 | 500 | 24 | 625 | 15 | 250 | 5 |
G:520-530 | ||||||||||
B:465-475 |
Other Specifications
Protection grade | IP67 |
Working temperature(°C) | -25~+60 |
Storage environment temperature (°C) | -25~+70 |
Standard length | 5 |
Maximum cascade length(m) | 5 |
weight | / |
Remark
The test environment temperature is 25±2°C.
The above data are typical values; the actual parameters of the product may be different from the typical data; the data is subject to change without notice.
The above "/" means that this parameter is not required for the time being.
