US2AS/US2DS/US2GS/US2JS/US2KS/US2MS Glass Passivated Ultra Fast Recovery Rectifier Diode

Specifications

Model NO. :

US2MS

Luminous Intensity :

NO LIGHT

Color :

NO LIGHT

Structure :

SMAF/SMBF

Material :

Silicon

CURRENT :

Transport Package :

Tape Reel

Specification :

Surface Mount Package

Trademark :

Origin :

China

HS Code :

85411000

Supply Ability :

10000000000piece/Year

Package Size :

30.00cm * 40.00cm * 40.00cm

Package Gross Weight :

8.000kg

Place of Origin :

China

Certification :

ISO9001:2015, ISO14001:2015, IATF16949

MOQ :

3,000 Pieces

Price :

Negotiable

Delivery Time :

Peak Season Lead Time: one month Off Season Lead Time: within 15 workdays

Payment Terms :

LC, T/T, PayPal

Description

GLASS PASSIVATED JUNCTION HIGH EFFICIENCY RECTIFIER
Electronics Component

Part Number: US2AS TH U US2MS

Major Parameter:

Type	VRRM	IF	IR(25ºC)	IR(100ºC)	IR(125ºC)	VF	Trr	Outline
Type	V	A	μA	uA	uA	V	nS	Outline
US2AS	50	2.0	5.0		100	1.0	50	SMAF
US2DS	200	2.0	5.0		100	1.0	50
US2GS	400	2.0	5.0		100	1.3	50
US2JS	600	2.0	5.0		100	1.7	75
US2KS	800	2.0	5.0		100	1.7	75
US2MS	1000	2.0	5.0		100	1.7	75

Brand: JF

Package: SMAF Plastic
Manufacturer: Jinan Jingheng Electronics Co., Ltd.

Features:

Plastic package has Underwriters Laboratory Flammability Classification 94V-0

Glass passived junction

Low power loss, high efficiency

High surge current capability

High speed switching, Low leakage

Low forward voltage drop

High current capability, High reliability

High temperature soldering guaranteed:260 C/10 seconds at terminals

Component in accordance to RoHS 2011 65 EU

Application:
Used in power supply, lighting, auto, home appliance field
