Specifications
Model NO. :
HER207G
Structure :
Alloy
Material :
Silicon
Transport Package :
Ammo Box
Specification :
Through Hole
Trademark :
JF
Origin :
China
HS Code :
85411000
Supply Ability :
10000000000piece/Year
Place of Origin :
China
Certification :
ISO9001:2015, ISO14001:2015, IATF16949
MOQ :
3,000 Pieces
Price :
Negotiable
Delivery Time :
Peak Season Lead Time: one month Off Season Lead Time: within 15 workdays
Payment Terms :
LC, T/T, PayPal
Description
Product Description


HIGH EFFICIENCY RECTIFIER

Electronics Component

Part Number: HER201G THRU HER208G

Major Parameter:

Type VRRM IF IR(25ºC) IR(100ºC) IR(125ºC) VF Trr Outline
V A μA uA uA V nS
HER201G 50 2.0 5.0 100 1.0 50 DO-15
HER205G 400 2.0 5.0 100 1.3 50
HER206G 600 2.0 5.0 100 1.7 75
HER207G 800 2.0 5.0 100 1.7 75
HER208G 1000 2.0 5.0 100 1.7 75


Brand: JF

Package: DO-15 Plastic
Manufacturer: Jinan Jingheng Electronics Co., Ltd.

Features:

Plastic package has Underwriters Laboratory Flammability
Classification 94V-0
Low power loss, high efficiency
High surge current capability
High speed switching, Low leakage
Low forward voltage drop
High current capability, High reliability
High temperature soldering guaranteed:260 C/10 seconds at terminals
Component in accordance to RoHS 2011 65 EU

Application:

Product Parameters


Used in power supply, lighting, auto, home appliance field
