Specifications
Brand Name :
ZSX
Model Number :
J30J-15ZKP-A
Certification :
ISO9001
Place of Origin :
China
MOQ :
10 pcs
Price :
Depending on the quantity
Payment Terms :
T/T,D/P,Western Union
Supply Ability :
100000Pcs/Year
Delivery Time :
5-8 Days
Packaging Details :
Carton packaging
Name :
J30J Connector
Gender :
Female
Boday Material :
Metal
Insulator material :
PPS
Working temperature :
-55℃~+125℃
Specification :
9~144 pins
Description
ODM J30J Connector Female Mini D Sub Connectors Rectangular J30J-15ZKP-A
Rectangular Micro D Connectors With Shielding Braid Cable Clipper J30J-15ZKP-A

The J30J series of micro rectangular electrical connectors comply with GJB2446A (equivalent to MIL-DTL-83513), corresponding to the American MDM series products. They adopt precision twisted wire elastic pins (precision twist pins), with a contact piece spacing of 1.27mm. The product is compact in size with a metal casing available in 12 specifications ranging from 9 to 144 pins. The insulator material uses PPS to meet high-temperature resistance and aerospace application requirements. Plugs and sockets feature threaded locking, guidance, and misinsertion prevention. Termination forms include crimping, direct insertion, bending insertion, and welding, with crimped wire cross-sectional area of 0.1mm² to 0.15mm², suitable for interconnection of various electronic and electrical systems requiring high density, miniaturization, lightweight, and high reliability.

Product Performance Details
Product Model J30J-15ZKP-A Contact Resistance ≤10mΩ
Ambient Temperature -55℃~+125℃ Insulation Resistance ≥5000MΩ
Vibration 10Hz~2000Hz 196m/s² Medium Pressure Resistance 800V
Random Vibration Power spectral density 0.4G²/Hz, RMS acceleration 23.1G Mechanical Life 500 times
Impact 735m/s² 11ms Rated Current 3A
Physical Product Display
ODM J30J Female Micro D Connector with Precision Twist Pins, High-Temperature Resistance, and Threaded Locking
ODM J30J Female Micro D Connector with Precision Twist Pins, High-Temperature Resistance, and Threaded Locking
Product Appearance
ODM J30J Female Micro D Connector with Precision Twist Pins, High-Temperature Resistance, and Threaded Locking
Related Product Recommendations
ODM J30J Female Micro D Connector with Precision Twist Pins, High-Temperature Resistance, and Threaded Locking
ODM J30J Female Micro D Connector with Precision Twist Pins, High-Temperature Resistance, and Threaded Locking
Product Selection Reference
Shell Size
ODM J30J Female Micro D Connector with Precision Twist Pins, High-Temperature Resistance, and Threaded Locking
ODM J30J Female Micro D Connector with Precision Twist Pins, High-Temperature Resistance, and Threaded Locking
Appearance Diagram After Matching
ODM J30J Female Micro D Connector with Precision Twist Pins, High-Temperature Resistance, and Threaded Locking
Office Area
ODM J30J Female Micro D Connector with Precision Twist Pins, High-Temperature Resistance, and Threaded Locking
ODM J30J Female Micro D Connector with Precision Twist Pins, High-Temperature Resistance, and Threaded Locking
Production Plant Area
Machining Production Workshop
ODM J30J Female Micro D Connector with Precision Twist Pins, High-Temperature Resistance, and Threaded Locking
ODM J30J Female Micro D Connector with Precision Twist Pins, High-Temperature Resistance, and Threaded Locking
Precision Assembly Production Workshop
ODM J30J Female Micro D Connector with Precision Twist Pins, High-Temperature Resistance, and Threaded Locking
ODM J30J Female Micro D Connector with Precision Twist Pins, High-Temperature Resistance, and Threaded Locking
Glass-to-Metal Sealed Production Workshop
ODM J30J Female Micro D Connector with Precision Twist Pins, High-Temperature Resistance, and Threaded Locking
ODM J30J Female Micro D Connector with Precision Twist Pins, High-Temperature Resistance, and Threaded Locking
Obtained Certification Certificate
ODM J30J Female Micro D Connector with Precision Twist Pins, High-Temperature Resistance, and Threaded Locking
ODM J30J Female Micro D Connector with Precision Twist Pins, High-Temperature Resistance, and Threaded Locking
Customer Visit
ODM J30J Female Micro D Connector with Precision Twist Pins, High-Temperature Resistance, and Threaded Locking
ODM J30J Female Micro D Connector with Precision Twist Pins, High-Temperature Resistance, and Threaded Locking
Product Packaging
ODM J30J Female Micro D Connector with Precision Twist Pins, High-Temperature Resistance, and Threaded Locking
ODM J30J Female Micro D Connector with Precision Twist Pins, High-Temperature Resistance, and Threaded Locking
Packaging and Shipping
ODM J30J Female Micro D Connector with Precision Twist Pins, High-Temperature Resistance, and Threaded Locking
  • Standard export carton
  • Customized specifications including logo as per customer requirements
  • Delivery time: Within 24 hours for stocks, 3-4 weeks for mass production orders (based on different quantities, ODM, etc.)
FAQ
Q: Are you trading company or manufacturer?
A: Our company is a comprehensive manufacturer with 17 years of R&D, manufacturing and sales of Aeronautics and Astronautics and commercial RF microwave transmission components.
Q: What are the main products of your company?
A: Main products: RF coaxial connectors and adapters, RF cable assemblies, miniature rectangular electrical connectors and cable assemblies, coaxial waveguide converters and cable assemblies, glass insulator sealed connectors and other microwave products.
Q: Does your company accept customized products?
A: We accept ODM.
Q: Does your company provide free samples?
A: We support free samples with freight paid on delivery.
Q: What is the minimum order quantity of your company's products?
A: 200 pieces. The price is more expensive under 200 pieces.
Q: Which logistics company does your company ship through?
A: Our company cooperates with international logistics companies DHL, UPS, FedEx, TNT all year round to ensure our customers receive their goods quickly with the lowest shipping cost. There are also air and sea logistics.
Q: How long does it usually take to receive the goods?
A: Generally, 3-8 working days for international express, 5-8 working days for air freight.
Q: What payment methods does your company accept?
A: We accept L/C, T/T, Western Union, Trade Assurance (credit card & T/T).
Q: How long is your warranty?
A: The warranty period is three months.
