MIL-DTL-83513 Series J30J-9TJL Crimp Type 9 Pins Male Plug Connector With L-Shaped Locking
MIL-DTL-83513 Series J30J-9TJL Crimp Type 9 Pins Male Plug Connector With L-Shaped Locking
MIL-DTL-83513 Series J30J-9TJL Crimp Type 9 Pins Male Plug Connector With L-Shaped Locking
MIL-DTL-83513 Series J30J-9TJL Crimp Type 9 Pins Male Plug Connector With L-Shaped Locking
MIL-DTL-83513 Series J30J-9TJL Crimp Type 9 Pins Male Plug Connector With L-Shaped Locking
MIL-DTL-83513 Series J30J-9TJL Crimp Type 9 Pins Male Plug Connector With L-Shaped Locking
Specifications
Brand Name :
ZSX
Model Number :
J30J-9TJL-300MM
Certification :
ISO9001
Place of Origin :
China
MOQ :
10 pcs
Price :
Depending on the quantity
Payment Terms :
T/T,D/P,Western Union
Supply Ability :
100000Pcs/Year
Delivery Time :
5-8 Days
Packaging Details :
Carton packaging
Name :
J30J Connector J30J-9TJL
Gender :
Male
Boday Material :
Metal
Insulator material :
PPS
Working temperature :
-55℃~+125℃
Specification :
9~144 pins
Description
MIL-DTL-83513 Series J30J-9TJL Crimp Type 9 Pins Male Plug Connector With L-Shaped Locking
J30J-9TJL is a 9-pin micro rectangular male connector with crimp termination and L-shaped locking. It features reliable twisted-pin contacts, wide operating temperature from -55℃ to +125℃, strong shock and vibration resistance, widely used in aviation, Aeronautics and Astronautics, industrial control and communication equipment for stable miniaturized interconnection.
Product Performance Details
Product model J30J-9TJL Contact resistance ≤10mΩ
Ambient temperature -55℃~+125℃ Insulation resistance ≥5000MΩ
Vibration 10Hz~2000Hz 196m/s² Medium pressure resistance 800V
Random vibration Power spectral density is 0.4G²/Hz and the root mean square value of the total acceleration rate is 23.1G Mechanical life 500 times
Impact 735m/s² 11ms Rated current 3 A
Product Display
MIL-DTL-83513 Series J30J-9TJL Crimp Type 9 Pins Male Plug Connector With L-Shaped Locking MIL-DTL-83513 Series J30J-9TJL Crimp Type 9 Pins Male Plug Connector With L-Shaped Locking
Product Appearance Drawing
MIL-DTL-83513 Series J30J-9TJL Crimp Type 9 Pins Male Plug Connector With L-Shaped Locking
Related Product Recommendations
MIL-DTL-83513 Series J30J-9TJL Crimp Type 9 Pins Male Plug Connector With L-Shaped Locking MIL-DTL-83513 Series J30J-9TJL Crimp Type 9 Pins Male Plug Connector With L-Shaped Locking
Product Selection Reference
MIL-DTL-83513 Series J30J-9TJL Crimp Type 9 Pins Male Plug Connector With L-Shaped Locking MIL-DTL-83513 Series J30J-9TJL Crimp Type 9 Pins Male Plug Connector With L-Shaped Locking MIL-DTL-83513 Series J30J-9TJL Crimp Type 9 Pins Male Plug Connector With L-Shaped Locking
Production Facilities
Machining Production Workshop
MIL-DTL-83513 Series J30J-9TJL Crimp Type 9 Pins Male Plug Connector With L-Shaped Locking MIL-DTL-83513 Series J30J-9TJL Crimp Type 9 Pins Male Plug Connector With L-Shaped Locking
Precision Assembly Production Workshop
MIL-DTL-83513 Series J30J-9TJL Crimp Type 9 Pins Male Plug Connector With L-Shaped Locking MIL-DTL-83513 Series J30J-9TJL Crimp Type 9 Pins Male Plug Connector With L-Shaped Locking
Glass-to-Metal Sealed Production Workshop
MIL-DTL-83513 Series J30J-9TJL Crimp Type 9 Pins Male Plug Connector With L-Shaped Locking MIL-DTL-83513 Series J30J-9TJL Crimp Type 9 Pins Male Plug Connector With L-Shaped Locking
Certifications
MIL-DTL-83513 Series J30J-9TJL Crimp Type 9 Pins Male Plug Connector With L-Shaped Locking MIL-DTL-83513 Series J30J-9TJL Crimp Type 9 Pins Male Plug Connector With L-Shaped Locking
Customer Visits
MIL-DTL-83513 Series J30J-9TJL Crimp Type 9 Pins Male Plug Connector With L-Shaped Locking MIL-DTL-83513 Series J30J-9TJL Crimp Type 9 Pins Male Plug Connector With L-Shaped Locking
Product Packaging
MIL-DTL-83513 Series J30J-9TJL Crimp Type 9 Pins Male Plug Connector With L-Shaped Locking MIL-DTL-83513 Series J30J-9TJL Crimp Type 9 Pins Male Plug Connector With L-Shaped Locking
Packaging and Shipping
  • Standard export carton
  • As per customized specifications such as logo or others according to customers' requirements
  • Delivery time: Within 24 hours for stocks, 3-4 weeks for mass production orders (based on different quantities, ODM, etc.)
Frequently Asked Questions
Q: Are you trading company or manufacturer?
A: Our company is a comprehensive manufacturer with 17 years of R&D, manufacturing and sales of Aeronautics and Astronautics and commercial RF microwave transmission components.
Q: What are the main products of your company?
A: Main products: RF coaxial connectors and adapters, RF cable assemblies, miniature rectangular electrical connectors and cable assemblies, coaxial waveguide converters and cable assemblies, glass insulator sealed connectors and other microwave products.
Q: Does your company accept customized products?
A: We accept ODM.
Q: Does your company provide free samples?
A: We support free samples with freight paid on delivery.
Q: What is the minimum order quantity of your company's products?
A: 200 pieces. The price is more expensive under 200 pieces.
Q: Which logistics company does your company ship through?
A: Our company cooperates with international logistics companies DHL, UPS, FedEx, TNT all year round to ensure our customers receive their goods quickly with the lowest shipping cost. There are also air and sea logistics.
Q: How long does it usually take to receive the goods?
A: Generally, 3-8 working days for international express, 5-8 working days for air freight.
Q: What payment methods does your company accept?
A: We accept L/C, T/T, Western Union, Trade Assurance (credit card & T/T).
Q: How long is your warranty?
A: The warranty period is three months.
