48V 40A 220V 3KW 145VDC All In One Solar Charger Inverter
48V 40A 220V 3KW 145VDC All In One Solar Charger Inverter
48V 40A 220V 3KW 145VDC All In One Solar Charger Inverter
48V 40A 220V 3KW 145VDC All In One Solar Charger Inverter
48V 40A 220V 3KW 145VDC All In One Solar Charger Inverter
48V 40A 220V 3KW 145VDC All In One Solar Charger Inverter
Specifications
Brand Name :
Silk
Model Number :
SFD-OG-44830S60
Certification :
CE,FCC,MSDS,ROHS,UN38.3
Place of Origin :
CHINA
MOQ :
50pcs
Price :
USD 330$-372$ per pcs
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000 pcs per month
Delivery Time :
10-30 days
Packaging Details :
Hard Paper Carton with Foam From Top and Button
Input Voltage :
48V
Output Voltage :
230V
Output Current :
40A
Output Frequency :
50/60HZ
Type :
DC/AC Inverters
Inverter Efficiency :
>95%
Output voltage waveform :
Pure sine wave
AC charge current :
60A
PV charge curren :
0-80A
Maximum PV open circuit voltage :
145V
Battery type :
Lead acid or lithium battery
Size (L*W*D) :
426mm*322mm*124mm
Weight :
12.5kgs
Description

Product overview
HF series is a new all-in-one hybrid solar charge inverter, which integrates solar energy storage &means charging energy storage and AC sine wave output.Thanks to DSP control and advanced controlalgorithm, it has high response speed, high reliability and high industrial standard.

48V 40A 220V 3KW 145VDC All In One Solar Charger Inverter

Performance characteristics:

*Full digital voltage and current double closed loop control, advanced SPWM technology, output of pure sine wave.
*Two output modes: mains bypass and inverter output; uninterrupted power supply. ŸAvailable in 4 charging modes: Only Solar, Mains Priority, Solar Priority and Mains & Solar hybrid charging.
*Advanced MPPT technology with an efficiency of 99.9%.
*With the charging requirement (voltage, current, mode) settings, and suitable for various types of energystorage batteries.
*ON/OFF rocker switch for AC output control.
*Power saving mode available to reduce no-load loss.
*Intelligent variable speed fan to efficiently dissipate heat and extend system life.
*Lithium battery activation design, allowing access of lead-acid battery and lithium battery. Ÿ360 ° all-round protection with a number of protection functions. Such as overload,short circuit and overcurrent.
*Supply of a variety of user-friendly communication modules, such as RS485(GPRS, WiFi, Bluetooth), USB etc., and suitable for computer,mobile phones, Internet monitoring as well as remote operations.

48V 40A 220V 3KW 145VDC All In One Solar Charger Inverter

Specification:

item
value
Place of Origin
China
Guangdong
Brand Name
OKTANMAX
Model Number
OK-OG4850S60
Input Voltage
220/230Vac
Output Voltage
220/230Vac
Output Current
40A
Output Frequency
50Hz/60Hz
Output Type
Single
Size
426*322*124
Type
DC/AC Inverters
Inverter Efficiency
95%
Certificate
CE RoHS
Warranty
1 year
Weight
12.5Kg

Packing & Delivery:

48V 40A 220V 3KW 145VDC All In One Solar Charger Inverter
