8600kg Water Well Drilling Machine Full Hydraulic Operation With 350m Depth
8600kg Water Well Drilling Machine Full Hydraulic Operation With 350m Depth
8600kg Water Well Drilling Machine Full Hydraulic Operation With 350m Depth
8600kg Water Well Drilling Machine Full Hydraulic Operation With 350m Depth
8600kg Water Well Drilling Machine Full Hydraulic Operation With 350m Depth
8600kg Water Well Drilling Machine Full Hydraulic Operation With 350m Depth
8600kg Water Well Drilling Machine Full Hydraulic Operation With 350m Depth
8600kg Water Well Drilling Machine Full Hydraulic Operation With 350m Depth
Specifications
Brand Name :
RanCheng
Model Number :
RCF350C
Certification :
CE, ISO 9001:2000
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
100sets per Month
Delivery Time :
10-15 working days
Packaging Details :
It can be shipped by one 20" container
Dimension(L*W*H) :
6000×2000×2550mm
Hoist lifting capacity :
2T
Lifting force :
22T
Weight :
8600kg
Drilling Way :
Air compressor drilling or mud pump drilling
Operating System :
Full hydraulic operation
feeding speed :
0.5-5m/min
Description

8600kg Water Well Drilling Machine Full Hydraulic Operation With 350m Depth


Product Description

RCF350C has a maximum drilling depth of 350 meters and a drilling capacity of 350 mm. Its advanced hydraulic system and top drive drill bit provide high torque and smooth operation in harsh working conditions. This drill rig is compact and durable, ensuring stable and efficient drilling with low maintenance costs. It is an ideal choice for water wells, geothermal applications and mining. It is the trusted choice of professional drillers around the world!

Technical Parameters

Model RCF350C
Bore diameter(Hammer) 140-350mm
Bore depth 350m
Air consumption 17-35m³/min
Air pressure 1.7-3.5Mpa
Pipe diameter 89mm/102mm
Pipe length 1m/2m/3m/6m
Lifting force 22T
Lifting speed 3m/min
feeding speed 0.5-5m/min
Fast lifting speed 30m/min
Fast feeding speed 50m/min
Max torque of the rotary 6200-8500Nm
Rotary speed 55-115r/min
Hoist lifting capacity 2T
Mud Pump flow 450L/min (option)
High hydraulic leg 1.5m
Feeding efficiency 10-35m/h
Travel speed 2.5Km/h
Climb ability 30°
Dimension(L*W*H) 6000×2000×2550mm
Weight 8600Kg
Diesel engine 91KW Yuchai engine
Drilling way Air compressor drilling or mud pump drilling
Operating system Full hydraulic operation


Machine picture display

8600kg Water Well Drilling Machine Full Hydraulic Operation With 350m Depth8600kg Water Well Drilling Machine Full Hydraulic Operation With 350m Depth8600kg Water Well Drilling Machine Full Hydraulic Operation With 350m Depth8600kg Water Well Drilling Machine Full Hydraulic Operation With 350m Depth

8600kg Water Well Drilling Machine Full Hydraulic Operation With 350m Depth8600kg Water Well Drilling Machine Full Hydraulic Operation With 350m Depth
8600kg Water Well Drilling Machine Full Hydraulic Operation With 350m Depth
8600kg Water Well Drilling Machine Full Hydraulic Operation With 350m Depth
8600kg Water Well Drilling Machine Full Hydraulic Operation With 350m Depth
