Rebar Scanner, Rebar Locator RL-50(+), Concrete Strength Test Hammer
Rebar Scanner, Rebar Locator RL-50(+), Concrete Strength Test Hammer
Rebar Scanner, Rebar Locator RL-50(+), Concrete Strength Test Hammer
Rebar Scanner, Rebar Locator RL-50(+), Concrete Strength Test Hammer
Specifications
Brand Name :
RAYTECH
Model Number :
RL-50(+)
Certification :
ISO CE
Place of Origin :
China
MOQ :
1unit
Payment Terms :
Western Union, MoneyGram, T/T, L/C
Supply Ability :
500units per month
Packaging Details :
Standard Export Carton
Product Name :
Rebar Scanner, Rebar Locator RL-50(+), Concrete Strength Test Hammer
Bar diameter application range(mm) :
Diameter 6~50
The first measuring range(mm) :
6-90
The second measuring range(mm) :
7-180
Maximum permissible error of Bar diameter :
≤±1
Gross weight :
4kgs
Description

Rebar Scanner, Rebar Locator RL-50(+), Concrete Strength

Test Hammer

Rebar Scanner, Rebar Locator RL-50(+), Concrete Strength Test Hammer

Features:

  1. Investigation depth could reach 180mm.
  2. Single comprehensive probe. No need to replace during test.
  3. Backlight screen let instrument can be normal used under the condition of insufficient light.
  4. Machine software is complete. The report could be printed automatically connecting with computer.
  5. Grid scan of the rebar position.
  6. Profile scan of the rebar position.

Work Environment Condition:

  1. No strong alternating electromagnetic field.
  2. No corrosive gas in the air.
  3. Avoid larger vibration and impact.
  4. Avoid the LCD panel contact with sunlight directly.

Product Usage:

  1. Testing concrete cover thickness
  2. Test concrete member internal reinforcement position, rebar spacing, reinforcement position distribution.
  3. Estimation bar diameter
  4. Detection of cable and plumbing pipe

Technical specification:

Bar diameter application range(mm) Diameter 6~50
Maximum permissible error of Bar diameter ≤±1
Cover thickness measuring range
The first measuring range(mm) 6-90
The second measuring range(mm) 7-180

The maximum error of cover thickness:

The first measuring range (mm) The second measuring range (mm)
6-59 7-79 ≤±1
60-69 80-119 ≤±2
70-90 120-180 ≤±4

Standard Delivery

Main unit, software 1
USB connecting cable 1
Probe 1
Probe cable 1
Manual 1
Warranty card 1
Carry case 1

Optional accessory

Scan car 1
Car cable 1

Rebar Scanner, Rebar Locator RL-50(+), Concrete Strength Test Hammer

TAG: Concrete Test Hammer Rebound Test Hammer Schmidt Hammer

Rebar Locator Rebar Detector Rebar Scanner
