Standard Gauge Railway Axle , Railroad Wagon Axle 2276.475mm Length
Standard Gauge Railway Axle , Railroad Wagon Axle 2276.475mm Length
Standard Gauge Railway Axle , Railroad Wagon Axle 2276.475mm Length
Standard Gauge Railway Axle , Railroad Wagon Axle 2276.475mm Length
Specifications
Brand Name :
Railteco
Model Number :
Class F
Certification :
AAR/GOST/TSI/IRIS/ISO
Place of Origin :
China
MOQ :
One pcs
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
Annual capacity of 40000 pcs
Delivery Time :
45 to 60 days after advance payment
Packaging Details :
Railteco Standard Packing
Name :
Railway Type F Axle
Rail Gauge :
1435mm
Axle load :
32.4t
Axle length :
2276.475mm
Bearing center distance :
2006.6mm
Material :
LZ50, AAT Grade F, EA1N, EA4T, IRS 16/95
Description

Railway Axle Class F Axle For Freight Wagon Railroad Wagon Axles Train Axle Bogie Axle AAR / GOST / TSI Axle Standard Gauge Wagon Axle

Description of Railway Axle:

Freight Wagon Axle of Type F Standard Gauge

Parameter
Axle load 32.4t
Rail Gauge 1435mm
Axle length 2276.475mm
Journal Diameter 157.239mm
Wheel seat Diameter 222.25mm
Bearing center distance 2006.6mm
Standards TB/T 2945, AAR M-101, UIC 811-1, EN 13261, BS 5892 PART 1, IRS 16/95, JIS E 4502, KSR 9220, GOST 31334, AS 7515 and other customer's requirement.

MATERIAL STANDARD CHEMICAL COMPOSITION
C Mn Si P S Cr Ni Mo Cu V
EA1N EN13261 ≤0.4 ≤ 1.2 ≤ 0.5 ≤0.02 ≤0.02 ≤0.30 ≤0.30 ≤ 0.08 ≤ 0.30 ≤ 0.06
EA1T
A1N BS5892-1 ≤0.4 ≤ 1.2 ≤ 0.5 ≤0.04 ≤0.04 ≤0.30 ≤0.30 ≤ 0.08 ≤ 0.30 ≤ 0.05
A1T
A1(N) UIC811-1 ≤0.37 ≤ 1.12 ≤ 0.46 ≤0.04 ≤0.04 ≤0.30 ≤0.30 ≤ 0.05 ≤ 0.30 ≤ 0.05
A1(T)
Grade F AAR M-101 0.45-0.59 0.7-1 0.15-0.4 ≤0.045 ≤0.05 0.02-0.08
N IRS:R-16/95 ≤0.37 ≤1.12 0.15-0.46 ≤0.04 ≤ 0.04 ≤ 0.30 ≤ 0.30 ≤0.05 ≤ 0.30 ≤ 0.05
T
LZ50 TB/T 2945 0.47-0.57 0.6-0.9 0.17-0.40 ≤ 0.03 ≤ 0.03 ≤ 0.30 ≤0.30 ≤ 0.25
SFA60A JIS E 4502-1 ≤0.035 ≤0.04
SFA60B JIS E 4502-1 ≤0.045 ≤0.045
