Railroad Locomotive Axle Class E For Practical Wheeled Vehicles Train Axle
Railroad Locomotive Axle Class E For Practical Wheeled Vehicles Train Axle
Railroad Locomotive Axle Class E For Practical Wheeled Vehicles Train Axle
Railroad Locomotive Axle Class E For Practical Wheeled Vehicles Train Axle
Specifications
Brand Name :
Railteco
Model Number :
Class E
Certification :
AAR/GOST/TSI/IRIS/ISO
Place of Origin :
China
MOQ :
One pcs
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
Annual capacity of 40000 pcs
Delivery Time :
45 to 60 days after advance payment
Packaging Details :
Railteco Standard Packing
Name :
Railway Type E Axle
Rail Gauge :
1000mm
Axle load :
25t
Axle length :
1803.4mm
Bearing center distance :
1549.4mm
Material :
LZ50, AAT Grade F, EA1N, EA4T, IRS 16/95
Description

Railway Axle Class E Axle For Freight Wagon Meter Gauge Train Axle Railroad Wagon Axles Bogie Axle AAR / GOST / TSI Axle

Description of Railway Axle:

Axles are an integral component of most practical wheeled vehicles. In a live-axle suspension system, the axles serve to transmit driving torque to the wheel, as well as to maintain the position of the wheels relative to each other and to the vehicle body. An axle is the component of a wheelset, a wheelset is the wheel–axle assembly of a railroad car.

In other types of suspension systems, the axles serve only to transmit driving torque to the wheels; the position and angle of the wheel hubs is an independent function of the suspension system. This is typical of the independent suspensions found on most newer cars and SUVs, and on the front of many light trucks. These systems still have differentials, but will not have attached axle housing tubes. They may be attached to the vehicle frame or body, or integral in a transaxle. The axle shafts (usually constant-velocity type) then transmit driving torque to the wheels. Like a full floating axle system, the drive shafts in a front-wheel drive independent suspension system do not support any vehicle weight.

Freight Wagon Axle of Type E Meter Gauge

Parameter
Axle load 25t
Rail Gauge 1000mm
Axle length 1803.4mm
Journal Diameter 144.539mm
Wheel seat Diameter 212.6mm
Bearing center distance 1549.4mm
Certifications ISO9001, ISO14001, OHSAS18001, AAR, IRIS, TSI.
Standards TB/T 2945, AAR M-101, UIC 811-1, EN 13261, BS 5892 PART 1, IRS 16/95, JIS E 4502, KSR 9220, GOST 31334, AS 7515 and other customer's requirement.
Tests Chemical analysis, Metallographic, Mechanical analysis, Ultrasonic testing, Magnetic testing, Impact testing, Hardness testing, Surface quality and dimension report.
Material LZ50, JZ45, AAT Grade F, EA1N, EA1T, EA4T, IRS 16/95, SFA60A, and et.

Railroad Locomotive Axle Class E For Practical Wheeled Vehicles Train Axle

Railroad Locomotive Axle Class E For Practical Wheeled Vehicles Train Axle
