Light Weight Railroad Draft Gear High Capacity 2000-2300 KN Rated Resistance
Light Weight Railroad Draft Gear High Capacity 2000-2300 KN Rated Resistance
Light Weight Railroad Draft Gear High Capacity 2000-2300 KN Rated Resistance
Light Weight Railroad Draft Gear High Capacity 2000-2300 KN Rated Resistance
Light Weight Railroad Draft Gear High Capacity 2000-2300 KN Rated Resistance
Light Weight Railroad Draft Gear High Capacity 2000-2300 KN Rated Resistance
Light Weight Railroad Draft Gear High Capacity 2000-2300 KN Rated Resistance
Light Weight Railroad Draft Gear High Capacity 2000-2300 KN Rated Resistance
Specifications
Brand Name :
Railteco
Place of Origin :
China
MOQ :
One pcs
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
According to customer's demand
Delivery Time :
30-45 days
Packaging Details :
Railteco Standard Packing
Name :
Railway Draft Gear
Rated Resistance :
2000~2300 KN
Travel :
d83 mn
Delivered Capacity :
46~55 KJ
Regular Capacity :
54~65 KJ
Absorptivity :
e80%
Description

Railway Spare Parts Railway Wagon High Capacity Light Weight Draft Gear MT-2 / MK50 / MT-3 / HM-1 Type Railroad Buffer

Description of Railway Wagon Draft Gear:

We can produce and supply with you following type of draft gear for railway vehicles, ex: MT-2, MK50 Draft gear, MT-3 Draft gear and Stucki type etc.

1. MT-2 Grade-E steel standard TB/T2942-1999

2. MT-3 Grade-E steel standard TB/T2942-1999

3. Stucki Grade-E steel standard AAR M-201

1) Larger capacity, high absorptivity

2) Long overhaul period

3) Mark-50 buffer imitation.

4) AAR-901E standard

With the advantages of low impedance, large capacity, high absorptivity, steady performance, long lifetime, and easy to install and use, the buffer meets the requirement of braking for the general rail wagons and heavy wagons.

Specifications of Railway Wagon Draft Gear:

Rated Resistance 2000~2300 KN
Travel d83 mn
Delivered Capacity 46~55 KJ
Regular Capacity 54~65 KJ
Absorptivity e80%
Type Brakes
Dimension 555mm*320mm*227mm

As Example following:

110 buffer gear

Weight: 76kg Material: 30

Size: 320 230 460mm

Standards Governing the Materials: GOST 22253-76

Technical Standards: GOST 22253-76

Application: Railroad parts and components.

3-95 buffer gear

Weight: 170kg

Design travel: 95mm

Min rated draft gear capacity: 110kJ

Technical Standards: GOST 19433-88

Application: Railroad parts and components.

Model Material Standard
MT-2 Grade E casting steel TB/T2942-1999
MT-3 Grade E casting steel TB/T2942-1999
Stucki Grade E casting steel AAR M-201

Name Main Parameters
X (mm) Y (mm) Z(mm) Weight(kg)
MT-2 Draft gear ≤561 320 227 175

Model

 Main Performance Parameters
resistance Stroke initial capacity official capacity absorptivity
(MN) (mm) (KJ) (KJ) %
MT-2 Draft gear ≤2.27 ≤83 ≥40 ≥50 ≥80
