DTS Laser Methane Detector Remote Methane Leak Detector 150m
DTS Laser Methane Detector Remote Methane Leak Detector 150m
Specifications
Brand Name :
DTS
Model Number :
DTS-R2
Place of Origin :
China
Certification :
CNEX SIL
MOQ :
1
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
1000
Packaging Details :
Carton
Customized Support :
OEM, ODM
Origin :
China
Detect Object :
Methane(CH4)
Detection Range :
0-100000ppm.m
Effective Detection Distance :
150m
Power Supply :
3.7V Rechargable Li-ion Battery
Operating Temperature :
-25°C-50°C
Operating Humidity :
0-95% RH
Description

DTS-R2 Remote Laser Methane Gas Detector 150m Distance 0-100000ppm.m

Product Description:

DTS-R2 Remote Methane Gas Leak Detector is hand-held laser remote methane gas leak detector. It is a high-tech advanced technology that detects methane leaking from long distances.It is a new generation of leak detection products, which greatly improves the efficiency and safety of walking inspection, the instrument available, widely recognized worldwide.

DTS-R2 Remote Laser Gas Leak Detector is a gas detection equipment specially designed to remotely detect methane, as well as other gas mixtures containing methane (natural gas or similar gases).


It allows to quickly and safely find the point of gas leakage by pointing the laser beam at the studied area.

Features:

  • ◇Remote measurement and detection, up to 200 meters (using a reflect sheet).
    ◇Compact, small, lightweight, easy to operate and maintenance free.
    ◇No specialist or special access equipment required to detect leaks.
    ◇Just respond to isolated strong absorption line of methane molecule that avoid to be interfered by other gas ingredients.
    ◇High sensitivity and very short response time(≤100ms)

    ◇Automatic self-check during start-up ensures consistent performance and reliability every time unit are turned on.

    ◇Green laser guide light is highly visible even under strong sunlight simplifying the task of locating leaks.
    ◇It can be widely used for detecting leak of natural gas transferring pipe, environment of natural gas station and concentration of coal mine gas.

Technical Parameters:

Parameter Value
Laser Safety Guide laser:Green Class 3R not direct to eyes; Measurement laser:Class 1 safe for eyes
Detection Range 0-100000ppm.m
Response Time Less Than 100ms
Detection Distance 150m
Resolution 5ppm.m
Fault Warning Audible-visual Alarm,Vibration Alarm, Light Alarm
Power Supply 3.7V Rechargable Li-ion Battery
Protection level IP66

EX proof safety

 Exib IIC T4 Gb
Humidity 95% RH, non-condensing
Operating Temperature -25°C-50°C
Weight 900g
Size 196*146*66mm

Applications:

DTS Laser Methane Detector Remote Methane Leak Detector 150m

DTS Laser Methane Detector Remote Methane Leak Detector 150m

DTS Laser Methane Detector Remote Methane Leak Detector 150m
