High Precision Reciprocating Piston Flow Meter Horizontal / Vertical Installation
High Precision Reciprocating Piston Flow Meter Horizontal / Vertical Installation
High Precision Reciprocating Piston Flow Meter Horizontal / Vertical Installation
High Precision Reciprocating Piston Flow Meter Horizontal / Vertical Installation
High Precision Reciprocating Piston Flow Meter Horizontal / Vertical Installation
High Precision Reciprocating Piston Flow Meter Horizontal / Vertical Installation
High Precision Reciprocating Piston Flow Meter Horizontal / Vertical Installation
High Precision Reciprocating Piston Flow Meter Horizontal / Vertical Installation
Specifications
Brand Name :
QINWEIYB
Model Number :
QWLZB-49
Place of Origin :
China
MOQ :
1Set
Price :
Negotiable
Payment Terms :
Western Union,T/T,D/P,D/A,L/C
Supply Ability :
100PCS/Month
Delivery Time :
5-8 work days
Packaging Details :
Carton
Flow Range :
0.1 to 1000 liters per minute
Fluid Compatibility :
Water, oil, chemicals, viscous fluids
Installation Orientation :
Horizontal or vertical
Product Name :
Positive Displacement Flowmeter
Measurement Principle :
Positive Displacement
Temperature Range :
-40°C to 150°C
Pressure Rating :
Up to 400 bar
Output Signal :
Pulse / Analog / Digital
Repeat Ability :
±0.1%
Power Supply :
24 VDC / 110 VAC / 220 VAC
Description

High-Precision And Micro-Flow Capacity Reciprocating Piston Flowmeter

The reciprocating piston flowmeter is a device that accurately sucks in, isolates and discharges the fluid by the reciprocating motion of the piston in the precise cylinder barrel, and measures the volume or flow rate of the fluid by measuring the displacement times or speed of the piston.

Advantages
  1. Extremely high precision: In calibration mode, the precision is the highest among all flowmeter principles because it is based on physical benchmarks of length and area.
  2. Infinite resolution: The displacement of the piston can be continuously measured, and theoretically, it can respond to even the slightest volume changes.
  3. Suitable for highly viscous fluids and very low flow rates: The thrust of the piston can overcome the resistance of high viscosity; as a flowmeter, it can measure extremely low flow rates down to ml/min or even μl/min, making it an ideal choice for micro flowmeters.
  4. Insensitive to fluid properties: The principle is only related to volume and is minimally affected by viscosity, density, conductivity, etc. (mainly considering leakage).
  5. Can be used as an absolute standard.
Typical application scenarios
  1. Flow measurement value traceability and calibration (highest-level laboratories): liquid flow standard devices for national metrology institutes, defense, aerospace, and high-end instrument manufacturers.
  2. Precise micro-flow measurement and control: medical devices, analytical instruments, chemical additives, fuel injection testing.
  3. Special fluid metering: accurate bulk shipment of high-viscosity polymers, expensive or hazardous chemicals.

Reciprocating piston flow measurement technology represents the "peak of accuracy" and the "eye for minute flows" in the field of flow measurement.
