Mining Industrial PU Fine Mesh Screens with 0.075-0.18mm Aperture for Abrasion Resistance and Low Noise Long Wear Life
Mining Industrial PU Fine Mesh Screens with 0.075-0.18mm Aperture for Abrasion Resistance and Low Noise Long Wear Life
Mining Industrial PU Fine Mesh Screens with 0.075-0.18mm Aperture for Abrasion Resistance and Low Noise Long Wear Life
Mining Industrial PU Fine Mesh Screens with 0.075-0.18mm Aperture for Abrasion Resistance and Low Noise Long Wear Life
Mining Industrial PU Fine Mesh Screens with 0.075-0.18mm Aperture for Abrasion Resistance and Low Noise Long Wear Life
Mining Industrial PU Fine Mesh Screens with 0.075-0.18mm Aperture for Abrasion Resistance and Low Noise Long Wear Life
Mining Industrial PU Fine Mesh Screens with 0.075-0.18mm Aperture for Abrasion Resistance and Low Noise Long Wear Life
Mining Industrial PU Fine Mesh Screens with 0.075-0.18mm Aperture for Abrasion Resistance and Low Noise Long Wear Life
Specifications
Brand Name :
Mam Ba
Model Number :
PFS
Certification :
ISO9001 SGS
Place of Origin :
China
MOQ :
5 Square Meter
Price :
negotiable
Payment Terms :
L/C,T/T,D/P,Western Union,MoneyGram
Supply Ability :
5000SM/Week
Delivery Time :
Within10-20days
Packaging Details :
On Wooden Carton
Products Name :
Fine Mesh Screens
Material :
High Quality PU and Steel Wire
Screening Feature :
Fine Higher Screening Accuracy
Width :
0.6-1.6m
Length :
0.7-3.5m
Working Feature :
Low noise and Longer Wear Life
Opening Area :
32% – 42%
PU Hardness :
80-87A
Thickness :
5-7mm
Resilience :
45%-47%
Aperture Type :
Slot
Aperture Sizes :
0.075-0.18mm
Description
Mining Industrial PU Fine Mesh Screens
Enhance productivity with 0.075-0.18 mm aperture polyurethane fine mesh screens designed for high-frequency vibrating screens.
Product Specifications
  • Normal Screen Size: 1040×700mm
  • Aperture Range: 0.075-0.18mm
  • Service Life: 6-12 months
  • Material: High-quality Polyurethane
  • Compatible with High Frequency Vibrating Screens
  • Available Colors: Orange, Red, and custom colors
  • Screen Width Options: 0.6m, 0.7m, 0.8m, 1m, 1.2m
  • Screen Length Options: 0.7m, 0.8m, 1m, 1.045m, 1.2m, 1.245m, 1.5m, 2m
  • Hook Type: Polyurethane hook system
Key Features
  • Excellent abrasion and wear resistance
  • Superior acid and alkali resistance
  • Fine openings for precise separation
  • Inlaid wedge-shape structure enhances tensile strength
  • Non-blinding design
  • Compatible with most vibrating screen types
  • Lightweight for easy installation and replacement
  • Low operating and maintenance costs
  • Reduced noise operation
  • Extended service life
  • High open area: 32%-42%
  • Custom mold designs available
Fine Particle Separation Performance
Our polyurethane fine screen mesh is manufactured from high-quality polyurethane sheets with precision screen surfaces. These screens offer superior abrasion resistance and significantly longer service life compared to traditional woven vibrating screen mesh. The anti-blinding properties enable efficient screening of materials previously considered difficult or impossible to process. With extremely fine openings down to 0.1mm, these screens are suitable for diverse wet and dry applications. The polyurethane construction ensures low noise operation and minimal maintenance requirements, making them ideal replacements for perforated vibrating screen mesh.
Detailed Specification Table
Item Slot Width (mm) Slot Length (mm) Open Area (%)
APF-010.102.5928.8
APF-020.122.5920.20
APF-030.152.7528.90
APF-040.182.1229.64
APF-050.202.5925.80
APF-060.232.5927.80
APF-070.252.5930.20
APF-080.402.5931.90
APF-090.504.3033.50
APF-100.604.3036.40
APF-110.705.2039.33
APF-120.805.2040.60
APF-131.005.7543.35
APF-141.508.2037.91
High Frequency Screening Applications
Fine screening involves separating particles in the range of 10 mm to 38 microns (400 mesh). In wet fine screening applications, the screen surface quality directly impacts separation efficiency and overall screening performance. Our wear-resistant urethane screen panels provide high open area and anti-blinding properties that outperform conventional woven wire screens.
Technical Specifications
  • PU Hardness: 80-87A
  • Thickness: 5-7mm
  • Resilience: 45%-47%
  • Aperture Type: Slot
  • Aperture Sizes: 0.075-0.18mm
Mining Industrial PU Fine Mesh Screens with 0.075-0.18mm Aperture for Abrasion Resistance and Low Noise Long Wear Life
