Specifications
Type :
Testing Machine
Brand Name :
HAIDA
Place of Origin :
Guangdong, China
Application :
Plastic Testing, Rubber testing
customized support :
OEM, ODM
power :
380V
Protection Class :
/
Voltage :
380 V
warranty :
1 Year
Measurement accuracy :
±0.1mm
Measurement range :
djustable from 100*100~ 600*600mm
MOQ :
1
Description
Ceramic Test Machine Thermal Expansion Coefficient Tester

The Low Temperature Thermal Expansion Tester is designed to test the expansion and shrinkage characteristics of metal, ceramic, glaze material, fire-resistant materials, and other non-metallic materials during baking processes. This equipment is suitable for GB/T3810.8-2016 and ISO 10545.8-1995 tile thermal expansion coefficient testing standards.

Ceramic Test Machine Thermal Expansion Coefficient Tester

Model: 60100-HD

The system features automatic temperature control, data recording, saving, and printing capabilities. It displays temperatures and expansion coefficient curves, with the entire testing process managed by computer automation.

Technical Specifications
Maximum Stove Temperature 1000℃/1400℃/1600℃
Displacement Range ±2.5mm
Sensor Sensitivity 0.1μm
Measurement Accuracy 0.5μm
Temperature Control Accuracy ±1℃
Sample Size Ф6～10×50mm, 10×10×50mm
Power Supply 220V, 2KW
  • Automatic calculation of expansion coefficient and linear swelling capacity
  • Automatic adjustment of compensation factors
  • Computer-controlled testing process
Company Profile
Ceramic Test Machine Thermal Expansion Coefficient Tester
Our Partners
Ceramic Test Machine Thermal Expansion Coefficient Tester
Our Advantages
Our Service Commitment
  • 48-hour response time for technical issues
  • Solutions provided within 3 working days
  • Operation videos and English manuals available
  • Video conference support
Onsite Services
  • Device installation and setup
  • Equipment operation and test technology training
  • Equipment calibration services
  • Daily maintenance and equipment care
  • Free technical training for factory visits
  • 24-hour online contact support
  • Free software upgrades
Documentation & Resources
  • Product instructions and manuals
  • Product operation videos
  • Experiment test applications and reports
Technical Support Channels
  • 24-hour social media communication
  • Seamless email support
  • Video conferencing assistance
  • Onsite technical service available
