Specifications
Type :
Testing Machine
Brand Name :
HAIDA
Place of Origin :
Guangdong, China
Application :
Plastic Testing, Rubber testing
customized support :
OEM, ODM
power :
AC 220V, 50Hz
Protection Class :
/
Voltage :
220 V
warranty :
1 Year
Measurement accuracy :
±0.1mm
Measurement range :
djustable from 100*100~ 600*600mm
MOQ :
1
Description
Product Description
HAIDA Ceramic Test Machine MOR Machine / Ceramic Bending Tester

60094-HD

MOR Machine/Ceramic Bending Tester
The hydraulic and air pressure system of the machine can load average, which can reach the standard of GB/T3810.4-2016,
ISO10545-4:2014 ceramic tile testing requirement. It is widely used in the MOR testing of ceramic pipe, glaze tile, sanitary ware,
electric ceramic, and fire-resistance materials. After replacing the tools, it can also be used to test the bursting strength etc.

Specification
Max loading capacity
10000(N)
Tile size
100*100~600*600, 100*100~800*800, 100*10~1000*1000(mm), Customized specifications of 100*10~1200*1200mm are also available
Loading speed
5~700(N/S) The data is processed by the micro computer, so that it can reach the accuracy of 0.5%
Power supply
Single-phase, 220V, 50HZ.
It can be loaded at constant speed and display the loading rate digitally. It can be loaded at constant speed according to
GB/T3810.4-2016 and ISO 10545-4-2014 standards: 1N/(mm2*S)+0.2N/(mm2*S).
Company Profile
HAIDA Ceramic Test Machine MOR Machine / Ceramic Bending Tester
Our Partners
HAIDA Ceramic Test Machine MOR Machine / Ceramic Bending Tester
Our Advantages
Our Service
* If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days.
* We can offer operation video and English operation muanual.
* We can provide video-con.

Onsite Service:
* Device installation;
* Equipment Operation Test Technology training;
* Equipment Calibration;
* Daily maintenance and maintenance of equipment
* Free technical training for visiting factories
* 24-hour Online contact
* Free software upgrades
* Free information:
* Product Instruction;
* Product operation instruction/video;
* Experiment Test (test application, test report)

Device Problem Handling:
* Social media 24 hours online communication;
* Mail Seamless Docking;
* Video Conferencing;
* Artificial free door-to-door service
