WPC Decking Extrusion Machine with 120-150Kg/h Output, PLC Control System, and 6 Meters Calibration Table for Wood Plastic Composite Profiles
WPC Decking Extrusion Machine with 120-150Kg/h Output, PLC Control System, and 6 Meters Calibration Table for Wood Plastic Composite Profiles
WPC Decking Extrusion Machine with 120-150Kg/h Output, PLC Control System, and 6 Meters Calibration Table for Wood Plastic Composite Profiles
WPC Decking Extrusion Machine with 120-150Kg/h Output, PLC Control System, and 6 Meters Calibration Table for Wood Plastic Composite Profiles
WPC Decking Extrusion Machine with 120-150Kg/h Output, PLC Control System, and 6 Meters Calibration Table for Wood Plastic Composite Profiles
WPC Decking Extrusion Machine with 120-150Kg/h Output, PLC Control System, and 6 Meters Calibration Table for Wood Plastic Composite Profiles
WPC Decking Extrusion Machine with 120-150Kg/h Output, PLC Control System, and 6 Meters Calibration Table for Wood Plastic Composite Profiles
WPC Decking Extrusion Machine with 120-150Kg/h Output, PLC Control System, and 6 Meters Calibration Table for Wood Plastic Composite Profiles
Specifications
Heatingzones :
5 zones
Brand Name :
LB
Certification :
CE,ISO
Supply Ability :
15 SETS PER MONTH
Output :
120-150Kg/h
Price :
Negotiable（USD,EUR）
Packaging Details :
STANDARD PACKAGE
Outputcapacity :
1000-2000 kg/hour
Productwidthrange :
100-200 mm
Warranty :
12 MONTHS
Delivery Time :
45 WORKING DAYS
Place of Origin :
ZHANGJIAGANG
Calibration Table :
6 METERS
MOQ :
1 SET
Payment Terms :
L/C,T/T
Model Number :
LB-300
Cooling Way :
SPRAYING NOZZLE
Controlsystem :
PLC Control
Motor Power :
22-55KW
Rawmaterialcompatibility :
Wood powder, plastic, additives
Description
WPC Decking Extrusion Machine For Wood Plastic Composite Profiles
Product Overview

Designed for PVC profile applications with flexibility in material choices, high performance, and long durability.

  • High flexibility in raw material combinations
  • Gentle and homogeneous plastification
  • Barrel with air cooling system
  • AC motors for low energy consumption
  • Control panel with color touch screen
Energy Saving System (LESS)

Lima Energy Saving System provides significant vacuum energy savings.

  • Vacuum energy savings up to 80%
  • Vacuum pumps driven by individual frequency inverters
  • Low noise level operation
  • Closed circuit water system
Crawler Track Haul-off Units

Flexible solutions with independent tracks and continuous speed adjustment.

  • Flexibility in pad dimensions
  • Two independent tracks with gearboxes
  • Speed adjustment by inverter
Complete Extrusion Line Components

Conical Twin Screw Extruder: Special screw and barrel design for perfect mixing and homogeneous output with motors for minimal electricity consumption.

Mould: Ideal viscosity design with polished contact surfaces to minimize friction losses.

Calibration Table: Stainless steel construction to prevent corrosion with customized design for profile characteristics.

Crawler Track Haul-off: Inverter-controlled speed adjustment synchronized with material output rate.

Saw Cutter: High-efficiency cutting with integrated dust collection system.

Tip-off Unit: Pneumatic cylinder operation.

Production Specifications
MODEL PROFILE SIZE (mm) EXTRUDER MODEL MOTOR POWER (kw)
LB-108 108 SJZ51/105 18.5 AC
LB-180 180 SJZ55/110 22 AC
LB-300 300 SJZ65/132 37 AC
LB-600 600 SJZ80/156 55 AC
LB-800 800 SJZ80/156 55 AC
LB-1240 1240 SJZ92/188 110 D
Product Gallery
WPC Decking Extrusion Machine with 120-150Kg/h Output, PLC Control System, and 6 Meters Calibration Table for Wood Plastic Composite Profiles WPC Decking Extrusion Machine with 120-150Kg/h Output, PLC Control System, and 6 Meters Calibration Table for Wood Plastic Composite Profiles WPC Decking Extrusion Machine with 120-150Kg/h Output, PLC Control System, and 6 Meters Calibration Table for Wood Plastic Composite Profiles WPC Decking Extrusion Machine with 120-150Kg/h Output, PLC Control System, and 6 Meters Calibration Table for Wood Plastic Composite Profiles
