Specifications
Brand Name :
LB
Model Number :
LB-180W
Certification :
CE,ISO
Place of Origin :
ZHANGJIAGANG
MOQ :
1 SET
Price :
USD,EUR
Payment Terms :
L/C,T/T
Supply Ability :
15 SETS PER MONTH
Delivery Time :
45 WORKING DAYS
Packaging Details :
STANDARD PACKAGE
EXTRUDER MODEL :
CONICAL TWIN SCREW EXTRUDER
PROFILE'S SIZE :
180MM
MOTOR POWER :
22KW
RAW MATERIAL :
WPC & ADDITIVES
CUTTER :
SAW CUTTER
CAPACITY :
100-150KG/H
Description
LANGBO MACHINERY provides advanced profile extrusion systems for PVC and WPC applications, focusing on higher quality, longer durability, and energy-saving solutions tailored to industry demands.
Key Components and Features
Conical Twin Screw Extruder
Designed specifically for PVC profile applications with optimal material flexibility, high performance, and long durability.
  • High flexibility in raw material combinations
  • Gentle and homogeneous plastification
  • Barrel with air cooling system
  • AC motors for low energy consumption
  • Control panel with color touch screen
Product Range: Screw diameters 51, 65, 80mm
Calibration Tables
Customized solutions for every application need with precision engineering.
  • Motor-driven height and side movement
  • Motor-driven longitudinal movement
  • Manual tilting movement
  • All water-contact parts made of stainless steel
Product Range: Table length from 4.5 to 14 meters, low maintenance cost
Crawler Track Haul-off Units
Flexible solutions with independent tracks and continuous speed adjustment.
  • Flexibility in pad dimensions
  • Two independent tracks with gearboxes
  • Speed adjustment by inverter
Product Range: Pad width 220-500 mm, Track length 1400-2000 mm
Cutting Systems
Multiple cutting options including saw (TK-series), guillotine (GK PRO), cross-cut (CC PRO), and blade cutting (BK-series) for various profile requirements.
Saw Cutter Features
  • Different saw dimensions for special profiles
  • Low maintenance cost
  • Includes dust absorber unit
  • Adjustable cutting speed
Tilting Table
  • Stainless steel table material
  • Pneumatic tilting system
  • Standard length: 6 meters (customizable)
  • Roller-type tables available for specific geometries
Complete System Components
  • Conical Twin Screw Extruder: Special screw and barrel design for perfect mixing, motors for low consumption, PLC automation with touch panel
  • Mould: Ideal viscosity design, polished contact surfaces to minimize friction
  • Calibration Table: Custom design for profile characteristics, stainless steel water-contact areas
  • Crawler Track Haul-off: Inverter-controlled speed adjustment synchronized with material output
  • Saw Cutter: High-efficiency cutting with integrated dust collection system
  • Tip-off Unit: Pneumatic cylinder operation
