Portable Multifunctional 4 in 1 Laser Fiber Welder 3000W High Power Laser Welder
Portable Multifunctional 4 in 1 Laser Fiber Welder 3000W High Power Laser Welder
Portable Multifunctional 4 in 1 Laser Fiber Welder 3000W High Power Laser Welder
Portable Multifunctional 4 in 1 Laser Fiber Welder 3000W High Power Laser Welder
Portable Multifunctional 4 in 1 Laser Fiber Welder 3000W High Power Laser Welder
Portable Multifunctional 4 in 1 Laser Fiber Welder 3000W High Power Laser Welder
Portable Multifunctional 4 in 1 Laser Fiber Welder 3000W High Power Laser Welder
Portable Multifunctional 4 in 1 Laser Fiber Welder 3000W High Power Laser Welder
Portable Multifunctional 4 in 1 Laser Fiber Welder 3000W High Power Laser Welder
Portable Multifunctional 4 in 1 Laser Fiber Welder 3000W High Power Laser Welder
Portable Multifunctional 4 in 1 Laser Fiber Welder 3000W High Power Laser Welder
Portable Multifunctional 4 in 1 Laser Fiber Welder 3000W High Power Laser Welder
Portable Multifunctional 4 in 1 Laser Fiber Welder 3000W High Power Laser Welder
Portable Multifunctional 4 in 1 Laser Fiber Welder 3000W High Power Laser Welder
Specifications
condition :
New
Output Power :
3000w
usage :
precision welding
Place of Origin :
Beijing, China
Brand Name :
ALAND
single pulse energy :
300J
pulse width :
0-2ms
Wavelength :
1080nm
focal spot diameter :
0.2 ~ 2.0 mm
dimensions :
900*600*980mm
warranty :
1 Year
laser source brand :
ALAND
laser head brand :
Other
servo motor brand :
Other
guiderail brand :
Other
control system brand :
Other
weight (kg) :
170 KG
key selling points :
Multifunctional
Laser model :
continue or modulation
Laser quality :
M2<1.2
output power stability :
2%
Machine rate input power :
9kw
Power supply :
3*380V,50/60Hz
Cooling system :
input/output temperature controled unit cooler
Fiber length :
5-10m
Environment temperature range :
15-35C
Welding speed :
0-120mm/s
fitting wire diameter :
0.8,1.0
Applicable Industries :
Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Farms, Home Use, Retail, Construction works , Advertising Company
Machinery Test Report :
Not Available
Video outgoing-inspection :
Not Available
Marketing Type :
New Product 2020
Warranty of core components :
1 Year
Core Components :
Laser Power Source
Description
Portable multifunctional 4 in 1 laser fiber welder 3000W high power laser welder
Portable Multifunctional 4 in 1 Laser Fiber Welder 3000W High Power Laser Welder
Portable Multifunctional 4 in 1 Laser Fiber Welder 3000W High Power Laser Welder
Portable Multifunctional 4 in 1 Laser Fiber Welder 3000W High Power Laser Welder
Portable Multifunctional 4 in 1 Laser Fiber Welder 3000W High Power Laser Welder
↓↓↓ ↓↓↓
Click Here To Get A Free Quote！✉
Product attribute
Model
FR-LA-1000
FR-LA-1500
FR-LA-2000
FR-LA3000
Laser Power
1000W
1500W
2000W
3000W
Power supply
1*220V, 50/60Hz
1*220V or 3*380V, 50/60Hz
3*380V, 50/60Hz
Welding thickness
0.5-2mm
0.5-3mm
0.5-3.5mm
0.5-4mm
Welding speed
0-120mm/s
0-120mm/s
0-120mm/s
0-120mm/s
Wire diameter (mm)
0.8,1.0
0.8,1.0,1.2
0.8,1.0,1.2,1.6
0.8,1.0,1.2,1.6
Laser model
Continuous Wave or modulation
Laser wave length
1080nm±5
1080nm±5
1080nm±5
1080nm±5
Beam quality
M2<1.2
M2<1.2
M2<1.2
M2<1.2
output power stability
2%
2%
2%
2%
Power
6kVA
8kVA
9kVA
13kVA
Cooling system
input/output temperature controlled unit cooler
Fiber length
5-10m
5-10m
5-10m
5-10m
Environment temp. range
15-35ºC
15-35ºC
15-35ºC
15-35ºC
welding seam
<=2mm
<=3mm
<=4mm
<=5mm
Welding materials
Steel, Galvanized Steel, stainless steel, Aluminum alloy
fitting wire diameter (mm)
0.8,1.0,1.2
0.8,1.0,1.2,1.6
0.8,1.0,1.2,1.6
0.8,1.0,1.2,1.6
Machine dimension(LWH)
900*600*1060
Machine weight
160kg
160kg
170kg
170kg

Accessories:

* Main Machine
* Fiber Laser torch with fiber cable
* Automatic Wire Feeder with cable
* Laser Torch Nozzles different size
* Feeding roller (1.2V/1.6V)
* Safety Goggle
* Data line & Liner
* Tool Box
Portable Multifunctional 4 in 1 Laser Fiber Welder 3000W High Power Laser Welder
Use effect
Portable Multifunctional 4 in 1 Laser Fiber Welder 3000W High Power Laser Welder

Main Features:

* High quality semiconductor laser and stable cooling system
* The torch with a special nozzle suitable for welding at different angles and positions on the workpiece
* Easy operation and get high welding speed and high quality
The efficiency can be up2-10 times than TIG welding and economize on manpower.
* General staff can use it and no need special training.
* Special design welding stirrer can get best laser spot and wide welding width, high quality welding seam.
* You can fit wire by a separated wire feeder
* Light hand torch with 5-10m original Fiber
* Integrated design
* Long-life Accessories and save energy, lower use cost.
* Special safety protection function for welding worker.
* Main parts with high quality and long life.
Portable Multifunctional 4 in 1 Laser Fiber Welder 3000W High Power Laser Welder
Portable Multifunctional 4 in 1 Laser Fiber Welder 3000W High Power Laser Welder
Portable Multifunctional 4 in 1 Laser Fiber Welder 3000W High Power Laser Welder
Portable Multifunctional 4 in 1 Laser Fiber Welder 3000W High Power Laser Welder
Portable Multifunctional 4 in 1 Laser Fiber Welder 3000W High Power Laser Welder
Product Packaging
Portable Multifunctional 4 in 1 Laser Fiber Welder 3000W High Power Laser Welder
Portable Multifunctional 4 in 1 Laser Fiber Welder 3000W High Power Laser Welder
Portable Multifunctional 4 in 1 Laser Fiber Welder 3000W High Power Laser Welder

WHY CHOOSE US

THE MOST IMPORTANT THINGIS THAT OUR PRODUCTS ARE GUARANTEED
Portable Multifunctional 4 in 1 Laser Fiber Welder 3000W High Power Laser Welder

FAQ.

Q1. Why Choose us?- We have nearly 10 years experience in welding industry and export to all over the world. - We have experienced R&D team. We can
adjust the parameter and panels design as per your request.
- Most of key parts are adopted top brand to ensure the quality. Such as the IGBT of Infineon (Simens). - Each machine will be
inspected before shipping. - One year warranty, life-long technical support and design service.
Q2. Could you get a customized sample?
Yes, we can adjust some configuration and parameters as your request.It also includes OEM service.
Q3. How is your quality control?
We use the world-class quality inspection to make every machine strong, powerful and reliable. We inspect with the world class
quality testing to make every single machine strong, powerful and reliable.
Inpection is full range, covered from welding power source to wire feeders, welding torches and up to welding consumables and work
safety. Whether you want to weld with 2T/4T, GAS/NO GAS, our components, which have been perfectly tuned to your requirements,
acting as excellent quality and the best possible welding results.
Q4. What voltage could you provide?110V/220v, 220/380V, 230V etc.
We can make it as per your country voltage.Q5. Can you send me the video to show how the machine works?
At present, some machines have video. We will try to make video of featured machine in future.
Q6. Do you have engineer who can guide me to install system?
Yes, we have a professional team. They can teach you how to work with it.
Q7. How long is the lead time for welding machine?
If no stockes, usually it takes 30-35 days after confirmation of order.
