High Purity PSA Nitrogen Generator for Oil and Gas 99.9-99.99%
High Purity PSA Nitrogen Generator for Oil and Gas 99.9-99.99%
Specifications
Brand Name :
SINCE GAS
Model Number :
PN-200-39
Certification :
CE,ASME,DNV,CCS,BV,ABS,LR
Place of Origin :
Suzhou
MOQ :
1 set
Price :
Negotiated
Payment Terms :
L/C,T/T,Western Union,MoneyGram
Supply Ability :
80 sets per year
Delivery Time :
within 2-3 months
Packaging Details :
Normal exporting size
Application :
Oil and gas
Working pressure :
6-7 bar
Color :
Green
Purity :
99.9-99.99%
Funcation :
Emergency working/ safety
Name :
High Purity Nitrogen Generator
Description
PSA High Purity Nitrogen Generator / Mobile Nitrogen Generation Unit
Product Specifications
Attribute Value
Application Oil and gas
Working pressure 6-7 bar
Color Green
Purity 99.9-99.99%
Function Emergency working/safety
PSA Technology Overview

The Pressure Swing Adsorption (PSA) Nitrogen generation technology has been successfully implemented since the 1970s, with thousands of plants operating worldwide. Our systems have been supplied to customers in over 56 countries.

How PSA Technology Works

Air consists of 78% nitrogen and 21% oxygen. The PSA process separates these components by adsorbing oxygen through Carbon Molecular Sieves (CMS), leaving high-purity nitrogen as the product gas.

Three-Step Process
  1. Adsorption: Compressed air passes through a CMS-filled vessel where oxygen is adsorbed, producing nitrogen.
  2. Desorption: When CMS becomes saturated, the process switches to a second vessel while the first regenerates by releasing waste gases.
  3. Regeneration: Purged nitrogen from the active vessel accelerates CMS regeneration for the next cycle.
Key Benefits
  • German Technology: Proprietary advancements from our German collaboration enhance system performance.
  • Automated Operation: Fully automated systems require no operator intervention.
  • Energy Efficient: Optimized designs minimize power consumption while maximizing nitrogen output.
Technical Specifications
No Model Capacity (Nm³/h) Purity Power (KW) Overall Size (mm)
1 PN-3-39 3 99.9% 0.5 1800×1400×1500
2 PN-5-29 5 99.5% 0.5 1800×1400×1500
3 PN-5-295 5 99% 0.5 1800×1400×1500
4 PN-8-295 8 95% 0.5 1800×1400×1500
5 PN-5-49 5 99.99% 0.5 1800×1400×1800
6 PN-8-39 8 99.9% 0.5 1800×1400×1800
7 PN-12-295 12 99.5% 0.5 1800×1400×1800
8 PN-15-29 15 99% 0.5 1800×1400×1800
Note: Complete specifications available upon request. Contact Since Gas System Co., Ltd for full model details.
Why Choose Our Nitrogen Generators?
  • 10+ years of industry experience with 98% customer retention rate
  • CCS and TS certified manufacturing for quality assurance
  • Specialized in marine nitrogen generator systems
  • Advanced R&D team supporting installation and operation
