Liquid Nitrogen Generator 5-5000 Nm3/h 95-99.9995% Purity
Liquid Nitrogen Generator 5-5000 Nm3/h 95-99.9995% Purity
Specifications
Name :
Liquid Nitrogen Generator
Certificates :
/BV/CCS/ISO/TS
Capacity :
5-5000 Nm3/h
Purity :
95%-99,9995%
Dew point :
-70℃
Feature :
Powerful
Brand Name :
Joshining
Model Number :
Liquid Nitrogen Generator
Certification :
CE,ABS,CCS,BV,DNV,ASME,GOST,
Place of Origin :
Suzhou, China
MOQ :
1 set
Price :
Negotiate
Payment Terms :
Western Union,L/C,T/T,MoneyGram
Supply Ability :
1000 sets/year
Delivery Time :
2 months after received down payment
Packaging Details :
Exported standard package
Description
Powerful Liquid Nitrogen Generator / Ammonia Cracking Nitrogen Generation Plant
Attribute Value
Name Liquid Nitrogen Generator
Certificates /BV/CCS/ISO/TS
Capacity 5-5000 Nm3/h
Purity 95%-99.9995%
Dew point -70℃
Feature Powerful
Pressure Swing Adsorption Working Principle

PSA technology allows nitrogen molecules to be isolated from other molecules in compressed air (water, oxygen, CO2, etc). The carbon molecular sieve (CMS), the adsorbent in the generator, retains all those molecules and only lets the nitrogen pass through to the outlet. While the CMS in one vessel regenerates, a second connected vessel goes through the same adsorption cycle. These two connected vessels work together to ensure a near-continuous flow of nitrogen gas.

Liquid Nitrogen Generator Applications
  • Tire Filling
  • Pharmaceutical
  • Marine
  • Electronics
  • Food Processing & Packaging
  • Plastic
  • Heat Treatment
  • Others
Liquid Nitrogen Generator Benefits
  • Automated Operation - PSA Nitrogen Gas plants we manufacture incorporate complete automation and no personnel are required for operating the Gas plant.
  • Low Power Consumption - We guarantee very low power consumption for Nitrogen production by optimum design to efficiently use the compressed air and maximize production of Nitrogen gas.
Liquid Nitrogen Generator Specifications
No Model Capacity (Nm3/h) Purity Power (KW) Overall size (mm)
1 PN-3-39 3 99.9% 0.5 1800*1400*1500
2 PN-5-29 5 99.5% 0.5 1800*1400*1500
3 PN-5-295 5 99% 0.5 1800*1400*1500
4 PN-8-295 8 95% 0.5 1800*1400*1500
5 PN-5-49 5 99.99% 0.5 1800*1400*1800
6 PN-8-39 8 99.9% 0.5 1800*1400*1800
7 PN-12-295 12 99.5% 0.5 1800*1400*1800
8 PN-15-29 15 99% 0.5 1800*1400*1800
9 PN-10-49 10 99.99% 0.5 2000*1700*2250
10 PN-15-39 15 99.9% 0.5 2000*1700*2250
Note: More information please contact Since Gas System Co.,Ltd or send email to us directly
Why Customers Choose SINCE
  • Many years of experience and expertise in manufacturing and supplying gas plants
  • CCS, TS certified company for quality gas plants and best after-sale services
  • SINCE is one of the few companies with TS (Manufacture License of special equipment)
  • CCS (CHINA CLASSIFICATION SOCIETY) certified for marine nitrogen generator production
  • Excellent infrastructure with experienced and qualified engineers
  • Sophisticated R&D wing for plant installation and use support
