FCC Procet Industrial Midspan Poe Injector Input 100-240Vac
FCC Procet Industrial Midspan Poe Injector Input 100-240Vac
FCC Procet Industrial Midspan Poe Injector Input 100-240Vac
FCC Procet Industrial Midspan Poe Injector Input 100-240Vac
FCC Procet Industrial Midspan Poe Injector Input 100-240Vac
FCC Procet Industrial Midspan Poe Injector Input 100-240Vac
FCC Procet Industrial Midspan Poe Injector Input 100-240Vac
FCC Procet Industrial Midspan Poe Injector Input 100-240Vac
Specifications
Brand Name :
procet
Model Number :
PT-PSE109GBRO-A
Certification :
CE FCC
Place of Origin :
CHINA
MOQ :
1PCS
Payment Terms :
T/T, L/C
Supply Ability :
500PCS
Delivery Time :
Sample for 24 hours / Order within 20Days
Packaging Details :
214 X 134 X 41mm
Key Features :
designed for indoor use but can work outdoor by covered with waterproof case
Model :
PT-PSE109GBRO-A
.Mounting: :
Wall- mounted/ Pole-mounted.
Operating Humidity :
20% to 80%,non-condensation
Output :
55Vdc 1750mA
Input voltage :
100 to 240Vdc
Storage Temperature: :
-40℃ to 85℃
Surge Protection :
6Kv
power :
95W
LED Indicator Power Indicator :
Green PoE Load Indicator: Green
Description

Procet Industrial midspan poe injector Input 100-240Vac Output 55V/1750mA Working temperature -40℃ to 85℃

Key Specifications/Special Features:

PT-PSE109GBRO-A

1. Procet Industrial SFP Fiber 95W PoE injector, Input 100-240Vac, Output 55Vdc 1750mA, Surge protection 6Kv, Working temperature at
-40℃ to 65℃, Gigabit data rates
2. PT-PSE109GBRO-A POE Injector is a single port midspan Injector with 4 Pair PoE up to 95 watts of power at 55 Vdc at 1.75 Amp.
3. Enclosed in an IP20 high-impact metal case, designed for indoor use but can work outdoor by covered with waterproof case. It works with a
wide input voltage of 100-240VAC with 6KV surge protection, 50 or 60 Hz and operates under -40℃ to +65℃. The effective distance limitation is
100 meters over Cat5e/Cat6 cables.
Parameter Description
Key Features

Industrial PoE can be outdoor use by covered with waterproof case
Extend temperature from -40℃ to 65℃

SFP Fiber Function
Lighting Protection at PoE port
Gigabit data rates
IP20 high-impact metal enclosure

AC power cord with optional US or EU plug or other standard plug

Diagnostic LEDs
Part Number PT-PSE109GBRO-A
Ports condition LAN Port*1, AC Input Port*1, PoE Output Port*1, SFP Port*1
Regulatory Compliance IEEE802.3bt
RoHS Compliance
WEEE Compliance
Pass Through Data Rates 10/100/1000 Mbps
Output Pin Assignment and Polarity:
4/5(+), 7/8(-) and 3/6(+),1/2(-)
Output Power Voltage: 55Vdc
User Port Power: 95W Guaranteen
Input AC Input Voltage:100to 240Vac(100 to 240Vac Rated)
AC Input Current: 2.0A
Frequency: 47 to 63Hz (50/60Hz Typ.)
Working Environment Operating Temperature: -40℃ to 65℃
Operating Humidity: 20% to 80%, non-condensation
Storage Temperature: -40℃ to 85℃
Storage Humidity: 10% to 90%, non-condensation
Operating Altitude: up to 5000meters
PoE Surge Protection Protected line: 1,2,3,4,5,6,7,8
Common mode surge protection(10/700us): 6KV
Differential mode surge protection (10/700us): 1.5KV
AC Surge Protection Line-Earth 1.2/50us (8/20us): 2KV
Line-Line 1.2/50us (8/20us): 1KV
Mechanical Characteristics Case: Metal
Color: Black
Mounting:Wall-mounted
IP Rated: IP20
Connectors: Shielded RJ-45*2
Size: 214 X 134 X 41mm
Weight: 1070g(2.36lb)
LED Indicator Power Indicator: Green
PoE Load Indicator: Green
Warranty 2 year
Safety Approvals cUL/UL, CE, CB, FCC

FCC Procet Industrial Midspan Poe Injector Input 100-240Vac

FCC Procet Industrial Midspan Poe Injector Input 100-240Vac

FCC Procet Industrial Midspan Poe Injector Input 100-240Vac

FAQ

Q: Are you manufacturer or trading company?

A: Manufacturer, and industry network total solution provider.

Q: Do you accept ODM/OEM?

A: Yes. We provide customized service.

Q: What is your minimum order quantity?

A: MOQ is 1 unit.

Q: What’s the payment type?

A: T/T, L/C,Western Union, Money Cram, Credit Card, Alipay, Cash.

Q: What’s the accepted trade terms?

A: EXW, FOB, CIF, FAS, CIP, FCA, CPT, DED, etc.

Q: How about shipping time?

A: Within 3-15 days after receiving full payment , but if you need OEM/ODM, the lead time depends on the specific specifications of the product.

Q: How about after-sales service?

A: 7/24 hours online and respond to user's field device problems in time.

Q: How about the warranty?

A: 5 years.
