Dual-port Industrial PoE Lightning Arrester Ethernet, Operates from -40℃ to +85℃, Offers 10kv Surge Protection​

Technical Parameter :

Mechanical Characteristics
- Case: Zinc alloy
- Color: Grey
- Mounting: DIN Rail mounted or Wall mounted
- IP Rated: IP40
- Size: 53.2mm X 86.6mm X 34.5mm
- Weight: 380g

PoE Surge Protection
- Max Discharge Current: 10KA(8/20us,1.25KA per line)
- Protected Line: 1,2,3,4,5,6,7,8
- Common Mode Protection Level(10/700us): 10KV
- Differential Mode Protection Level(10/700us): 1.5KV
- Insertion Loss @10MHz/100MHz:-1db
- Return Loss @10MHz/100MHz: -20db
- Response Time:5ns

Standard
- IEEE802.3 10Base-T Ethernet
- IEEE802.3u 100Base-Tx Fast Ethernet
- IEEE802.3ab 1000Base-T Gigabit Ethernet
- Support PoE wire with IEEE802.3af/at standards
- Support 120W IEEE802.3bt and PoE++ standards
- RoHS Compliance
- WEEE Compliance

Schematic Diagram:
