Description
Product details
304 316 Stainless Steel Chain Plate Link Perforated Mesh Conveyor Belt
Description :
Plate belt is a very robust belt that is made of stainless steel and driven by sprocket. Perfect for conveying small products,
smooth running, easy to maintain, durable, constructed of plates or hanges linked together by means of cross rods. The belt is
almost always equipped with side chains. The chains are secured by a ring welded at the cross rods ends.

Pls advise the data in the following drawing before making our best offer.
Stainless Steel Wire Mesh Conveyor Belt with perforated metal chain plate design and side chains secured by welded rings
Product Description
Specification of Perforated Metal Chain Plate Conveyor Belt
Material
carbon steel, SUS 201 304 316
Plate thickness
0.8mm 1mm 1.2mm 1.5mm 2mm 2.5mm 3mm or customized
Perforated hole diameter
4mm 5mm 6mm 7mm 8mm, etc
Cross rod diameter
5mm 6mm 8mm 10mm 12mm or customized
Chain pitch
19.05mm 25.4mm 31.75mm 38.1mm 50.8mm 76.2mm or customized
Width
0.2m to 4m
Length
customized
Stainless Steel Wire Mesh Conveyor Belt with perforated metal chain plate design and side chains secured by welded rings
Feature
1. It can be the delivery of granular materials, can also be carried into the delivery of items.
2. Suitable for high density transportation in small.
3. Smooth motion,force
4. Convenient installation and replacement,high cost,long service life.
Stainless Steel Wire Mesh Conveyor Belt with perforated metal chain plate design and side chains secured by welded rings
Stainless Steel Wire Mesh Conveyor Belt with perforated metal chain plate design and side chains secured by welded rings
Application
1. Fast frozen machine,baking machine, plane conveyor, screw conveyor.
2. Cleaning,sterilization,drying ,cooking,cooling and so on for food machine.
3. Losing bottle annealing,roast flower etc for glass machine .
4. Eachi kinds of pipeline transport.
5. Metal process:powder metallurgy, heat treatment ,hardening, sintering, brazing, roasting, brightening, blacking, bearing,
carburizing high-temperature.
6. Washing machine,winding machine,drying machine, etc.
Stainless Steel Wire Mesh Conveyor Belt with perforated metal chain plate design and side chains secured by welded rings
Stainless Steel Wire Mesh Conveyor Belt with perforated metal chain plate design and side chains secured by welded rings
