Stainless Steel Ladder Wire Mesh Conveyor Belt Chocolate Enrobing Chain Link for Oven Baking
Stainless Steel Ladder Wire Mesh Conveyor Belt Chocolate Enrobing Chain Link for Oven Baking
Stainless Steel Ladder Wire Mesh Conveyor Belt Chocolate Enrobing Chain Link for Oven Baking
Stainless Steel Ladder Wire Mesh Conveyor Belt Chocolate Enrobing Chain Link for Oven Baking
Stainless Steel Ladder Wire Mesh Conveyor Belt Chocolate Enrobing Chain Link for Oven Baking
Stainless Steel Ladder Wire Mesh Conveyor Belt Chocolate Enrobing Chain Link for Oven Baking
Specifications
Payment Terms :
T/T, Western Union,
Material :
Stainless steel 304,316,314
Feature :
heat resistance,food grade
Supply Ability :
500 meters per months
Name :
Stainless Steel Ladder Wire Mesh Conveyor Belt Chocolate Enrobing Chain Link for Oven Baking
Wire diameter :
0.5mm-3mm
Processing Service :
Bending，woven
Certification :
FDA
Model Number :
CAR-0081
Application :
Food & Beverage Factory, Food Shop
MOQ :
10 meters
Delivery Time :
5-20days
Rod Pitch :
5mm-8mm
Place of Origin :
China
Packing :
Wooden case
Price :
Negotiable
Width :
0.5m-2m
Brand Name :
Comesh
Accessories :
Gears available.
Packaging Details :
plastic bag inside wooden case outside
Description

Stainless Steel Ladder Wire Mesh Conveyor Belt Chocolate Enrobing Chain Link for Oven Baking

Chocolate conveyor belts are usually gear transmission belt, with good ventilation advantages, tension evenly, fine workmanship, with a flexible rotation, good stability, High temperature, pressure resistance, corrosion resistance, long life and so on.
Chocolate conveyor belts are used with a single-layer structure, lighter, the use of sprocket drive. Large open area (opening 70-85%), often used in the lighter weight of the product cooling, frying, baking, drying, heating, decoration, wrapped powder and packaging equipment.

1.The mainly material if 304 stainless steel wires from 1-3 mm
2.Simple structure.So the price is much more cheaper than other types of conveyor belt.
3.Technical:wire bending-connection-edge treatment.
4.Standard pitch:7.26 mm and 12.7 mm.we also accept customized size.
5.Matching : nylon sprocket,stainless steel sprocket.

Name Stainless Steel Ladder Wire Mesh Conveyor Belt Chocolate Enrobing Chain Link for Oven Baking
Material Stainless steel 304,316,310,314S
Wire diameter 0.8mm,1mm,1.2mm,1.5mm,2mm
Width 0.5m-3m
Rod Pitch 5mm-8mm

Advantage:

1. The sprocket drive ensures positive and stable running.

2. The rotation diameter is small, so that smooth products transfer is ensured.

3. Easy washing is ensured.

4. Because of large open area, high air permeability and dehydration capacity are ensured.

Application:

Stainless steel flat flex conveyor belts are used in many industries.The belts have a light weight single layer construction and are positively driven by sprockets.The belts have an open structure (70-85% open) and are frequently.Used in cooling,baking,drying,heating,decorating,battering and packing machines for light products.Flat flex belts are often used in conveyors for the food industry for the production of :snacks fish pizzas vegetables breadpastry-meat candy (small) potatoes biscuits chocolate nuts and fruits.

Stainless Steel Ladder Wire Mesh Conveyor Belt Chocolate Enrobing Chain Link for Oven Baking

Stainless Steel Ladder Wire Mesh Conveyor Belt Chocolate Enrobing Chain Link for Oven Baking

Stainless Steel Ladder Wire Mesh Conveyor Belt Chocolate Enrobing Chain Link for Oven Baking

Stainless Steel Ladder Wire Mesh Conveyor Belt Chocolate Enrobing Chain Link for Oven Baking

Stainless Steel Ladder Wire Mesh Conveyor Belt Chocolate Enrobing Chain Link for Oven Baking

Stainless Steel Ladder Wire Mesh Conveyor Belt Chocolate Enrobing Chain Link for Oven Baking
