Custom Size Honeycomb Mesh Conveyor Belt 304 Stainless Steel Made to Customer Drawing
Custom Size Honeycomb Mesh Conveyor Belt 304 Stainless Steel Made to Customer Drawing
Custom Size Honeycomb Mesh Conveyor Belt 304 Stainless Steel Made to Customer Drawing
Custom Size Honeycomb Mesh Conveyor Belt 304 Stainless Steel Made to Customer Drawing
Custom Size Honeycomb Mesh Conveyor Belt 304 Stainless Steel Made to Customer Drawing
Custom Size Honeycomb Mesh Conveyor Belt 304 Stainless Steel Made to Customer Drawing
Specifications
Certification :
ISO 9001:2015, SGS
MOQ :
2 Square Meters
Belt Type :
Custom size honeycomb belt
Side Wall :
Flat edges or optional side walls
Application :
Small parts, food, electronics, drying lines
Payment Terms :
T/T,Western Union,PayPal
Place of Origin :
Hebei, China
Delivery Time :
15-22 working days after deposit
Model Number :
CAR -HC-304
Custom Length :
Cut to customer drawing
Tolerance :
+/- 2 mm on width, +/- 10 mm on length
Packaging Details :
Waterproof film wrapped, plywood case with steel frame, export standard
Wire Diameter :
0.4 - 1.2 mm
Name :
Custom Size Honeycomb Mesh Conveyor Belt 304 Stainless Steel Made to Customer Drawing
Material :
SS 304 / 316L / 310S
Supply Ability :
500 Square Meters per Month
Cell Opening :
1.5 x 3 mm to 8 x 15 mm
Brand Name :
COMESH
Price :
USD 40-85 / Square Meter
Custom Width :
100 - 4000 mm per drawing
Description

Custom Size Honeycomb Mesh Conveyor Belt 304 Stainless Steel Made to Customer Drawing

This custom size honeycomb mesh conveyor belt is built to your drawing in 304 stainless steel, combining a dense honeycomb carrying surface with precise dimensional control for small parts, food and electronic component lines.

Key Features

  • Honeycomb cells form an ultra-dense flat surface that supports tiny and irregular items without dropping through.
  • Custom width, length and cell opening manufactured exactly to your drawing or sample.
  • 304 / 316L / 310S stainless steel options for food, chemical and high temperature environments.
  • Strict tolerance control with +/- 2 mm on width and +/- 10 mm on length.
  • Flat edges or optional side walls available to match your line configuration.

Technical Specifications

Item Specification
Material SS 304 / 316L / 310S
Belt Type Custom size honeycomb belt
Cell Opening 1.5 x 3 mm to 8 x 15 mm
Custom Width 100 - 4000 mm per drawing
Custom Length Cut to customer drawing
Wire Diameter 0.4 - 1.2 mm
Side Wall Flat edges or optional side walls
Tolerance +/- 2 mm on width, +/- 10 mm on length

Applications

  • Small parts and fastener conveying
  • Food products and confectionery lines
  • Electronic components and battery cells
  • Drying and cooling tunnels
  • Pharmaceutical small part handling

Send your drawing or sample belt to our team - we will confirm cell size, material and edge style for an accurate quotation.
