304 Stainless Steel Drying Oven Mesh Conveyor Belt Anti Corrosion Balanced Weave Wire Belt
304 Stainless Steel Drying Oven Mesh Conveyor Belt Anti Corrosion Balanced Weave Wire Belt
304 Stainless Steel Drying Oven Mesh Conveyor Belt Anti Corrosion Balanced Weave Wire Belt
304 Stainless Steel Drying Oven Mesh Conveyor Belt Anti Corrosion Balanced Weave Wire Belt
304 Stainless Steel Drying Oven Mesh Conveyor Belt Anti Corrosion Balanced Weave Wire Belt
304 Stainless Steel Drying Oven Mesh Conveyor Belt Anti Corrosion Balanced Weave Wire Belt
Specifications
Belt Width :
500mm - 3000mm
Application :
Drying Oven, Food Drying Line, Industrial Oven
Payment Terms :
T/T,L/C,PayPal
Model Number :
CM-S102
Weave Type :
Balanced Weave
Belt Length :
Per Customized Drawing
Place of Origin :
Hebei, China
Packaging Details :
Export-grade wooden pallets with moisture-proof wrapping, steel frame reinforcement
Delivery Time :
15-20 working days
Temperature Range :
-40°C to 800°C
Surface Finish :
Anti-Corrosion Passivated Finish
MOQ :
10 Square Meters
Edge Treatment :
Welded Selvage Edge
Certification :
ISO 9001:2015
Wire Diameter :
1.2mm x 2.0mm
Price :
USD 15-45 / Square Meter
Brand Name :
COMESH
Supply Ability :
1000 Square Meters per Month
Mesh Opening :
8mm x 8mm
Material :
SS304 Stainless Steel (SS316 Optional)
Description

304 Stainless Steel Drying Oven Mesh Conveyor Belt

This anti corrosion drying oven belt is woven from 304 stainless steel wire in a balanced weave structure, engineered for continuous drying ovens, food dehydration lines and industrial heat treatment furnaces. The passivated surface resists rust, oxidation and chemical attack, delivering long service life in humid and corrosive environments.

Anti Corrosion Protection

  • Passivated 304 stainless steel surface resists rust and oxidation
  • SS316 optional for salt-spray and acid-wash environments
  • Suitable for food drying, chemical and electroplating lines

Drying Oven Performance

  • Operating temperature up to 800°C without deformation
  • Balanced weave provides stable tracking and uniform airflow
  • Open mesh structure accelerates moisture evaporation

Specifications

Material SS304 Stainless Steel (SS316 Optional)
Weave Type Balanced Weave
Wire Diameter 1.2mm x 2.0mm
Mesh Opening 8mm x 8mm
Temperature Range -40°C to 800°C

Contact us for a custom drying oven belt quotation with your oven dimensions.
