Specifications
Brand Name :
GNEE
Certification :
SGS
Place of Origin :
CHINA
MOQ :
≥1sets
Price :
depend on product
Payment Terms :
MoneyGram,Western Union,T/T,D/P,D/A,L/C
Supply Ability :
Annual Production 30,000 tons
Delivery Time :
Transit time: Est. 17-24 days
Item :
cryogenic pressure tank (LO2,LN2,LAr)
Design Standard :
ISO,SGS,ASME
Insulation Methoned :
vaccum powder
Width :
2438mm
Warranty :
1 years
Medium :
LCo2
Durable Years :
20 years
Packing :
nude packing
Test Pressure :
0.8MPa-1.6MPa
Showroom Location :
None
Outer Cylinder Material :
Q345R
Pressure :
10~50kPa
Description

Factory Wholesale 1.84Mpa Cryogenic Storage Tank

Description of cryogenic tank


Cryogenic liquid storage tank is for double wall, the inner material adopted S30408 stainless steel,the outer material useing Q245R,carbon steel. It conclude vertical and horizontal structure, adopt the use of vacuum powder adiabatic, with the advantage of compact structure , low issuance date,small footprint,centralized control, safe,reliable, easy operation and maintenance.

Product Parameters


Effective volume
(M3)

Working pressure
(Bar)

Dimension
(mm)

Weight
(Kg)

5

8

Φ2000*5130

3412

10

8

Φ2100*7170

5378

15

8

Φ2500*6912

6415

20

8

Φ2500*8756

8255

30

8

Φ2900*8870

12899

50

8

Φ3100*12058

18960

100

8

Φ3600*15947

34480


1.84Mpa Cryogenic Storage Tank 2438mm Width Vacuum Powder Insulation1.84Mpa Cryogenic Storage Tank 2438mm Width Vacuum Powder Insulation

1.84Mpa Cryogenic Storage Tank 2438mm Width Vacuum Powder Insulation


1.84Mpa Cryogenic Storage Tank 2438mm Width Vacuum Powder Insulation


ABOUT US


We have more than 17 years of production experience and also have rich export experience. We have supplied industrial gas (O₂, N₂, Ar, CO₂, LNG, etc.) filling stations for foreign market more than10 years.Complete gas solutions,can be provided for customers. Of course,total package for the filling station can be done by us. Including installation,comssioining and start-up etc.

We have clients in Vietnam, South Korea, Kenya, Indonesia, Pakistan, Australia, the Unite States, Kazakhstan, Iran, and more than 32 country.Cooperate with us; you need not worry about quality and after-sale Service.You can check our products in our agent factory,we can also arrange engineer help you solve all product questions.


Want to obtain storage tank specifications suitable for your scenario (e.g., vertical/horizontal structure, anti-corrosion grade, sealing solution)? Consult us at any time, and we will respond quickly to your detailed needs.
