Pneumatic Releasing System NC Servo Roll Feeder High Precision for 400mm Width Material
Pneumatic Releasing System NC Servo Roll Feeder High Precision for 400mm Width Material
Pneumatic Releasing System NC Servo Roll Feeder High Precision for 400mm Width Material
Pneumatic Releasing System NC Servo Roll Feeder High Precision for 400mm Width Material
Pneumatic Releasing System NC Servo Roll Feeder High Precision for 400mm Width Material
Pneumatic Releasing System NC Servo Roll Feeder High Precision for 400mm Width Material
Pneumatic Releasing System NC Servo Roll Feeder High Precision for 400mm Width Material
Pneumatic Releasing System NC Servo Roll Feeder High Precision for 400mm Width Material
Pneumatic Releasing System NC Servo Roll Feeder High Precision for 400mm Width Material
Pneumatic Releasing System NC Servo Roll Feeder High Precision for 400mm Width Material
Specifications
Price :
$3,800/cases 1-4 cases
MOQ :
1
Payment Terms :
T/T
Supply Ability :
1set 7days
place of origin :
Guangdong, China
type :
Feeder Machine
use :
Sheet
video outgoing-inspection :
Provided
machinery test report :
Provided
core components :
PLC, Engine, Bearing, Motor
brand name :
Qiaosen
voltage :
380
power(w) :
1500
warranty :
1 Year
key selling points :
Easy To Operate
weight (kg) :
200
Feeding Speed :
15 m/min
Item name :
Pneumatic & Mechanical Feeding Straightening feeder
Keyword :
Straightening feeder
Width of material :
400mm
Thickness of material :
Max 3.2mm
Feeding capacity :
300W*2.3T
Feeding length :
0.01-9999.99mm
Roll pressure :
Spring type
Releasing system :
Pneumatic type
Pass line adjustment :
50mm
Power supply :
AC380V/3phase
Place of Origin :
China
Brand Name :
QIAOSEN
Certification :
CE / ISO14001
Description
NC200 NC300 NC400 NC-1000 Coil Servo Feeder Machine Core Motor Components Bearing for Metal Straightening Machinery Sheet Use
Servo Roller Feeder Punching Press Automatic Pneumatic & Mechanical Feeding Straightening feeder
Pneumatic Releasing System NC Servo Roll Feeder High Precision for 400mm Width Material
Product Specifications
Pneumatic Releasing System NC Servo Roll Feeder High Precision for 400mm Width Material
NC-400B NC Servo Roller Feeder
Feeds material for various thicknesses and feeding stroke lengths
Suitable for high-speed feeding and long stroke length feeding
User-friendly operation panel for inputting feeding length (0.01mm-9999.99mm) and speed
Pneumatic cylinder releasing method, malfunction-free operation
Optional mechanical releasing method available
High precision feeding: ±0.02mm
Supports 5 sets of different feeding lengths with 999 strokes quantity each
Normal manual running mode for easy material feeding to stamping mould
Effective releasing device based on press machine's cam position and material thickness
Touch screen interface for length input
Hollow feeding roller with HRC60 surface hardness and chrome plating
Structure Features
High-quality servo motor for efficient feeding testing
High-sensitivity encoder for precise feedback and improved accuracy
Quality belt system eliminates gear gap, abrasion, noise, and lubrication needs
Internally mounted motor for protection against damage
Pneumatic Releasing System NC Servo Roll Feeder High Precision for 400mm Width Material
Similar Products
Pneumatic Releasing System NC Servo Roll Feeder High Precision for 400mm Width Material
Pneumatic Releasing System NC Servo Roll Feeder High Precision for 400mm Width Material
Pneumatic Releasing System NC Servo Roll Feeder High Precision for 400mm Width Material
Pneumatic Releasing System NC Servo Roll Feeder High Precision for 400mm Width Material
Pneumatic Releasing System NC Servo Roll Feeder High Precision for 400mm Width Material
Pneumatic Releasing System NC Servo Roll Feeder High Precision for 400mm Width Material
Company Profile
Dongguan Qiaosen Machinery Co., Ltd, established in 2016, operates from our factory located in Jiangsu province near Shanghai city with convenient transportation access. Our factory was among the first to achieve ISO9001:2008 quality management system certification. We specialize in hydraulic press machine production, offering 10-ton to 2000-ton press machines across 8 series with over 100 types including single column, four column, C-frame, H-frame, and various press, punching, folding, and cutting machines. Our products serve aviation, aerospace, automotive, shipbuilding, light appliances, daily hardware, and other industries. Known for exquisite design, competitive pricing, excellent quality, and efficient after-sales service, our products have gained recognition from domestic and international customers, selling across more than 20 domestic provinces and exporting to the United States, Japan, Russia, European Union, Southeast Asia, the Middle East, and other countries.
