400mm Width Material Servo Roll Feeder with Pneumatic Releasing System
400mm Width Material Servo Roll Feeder with Pneumatic Releasing System
400mm Width Material Servo Roll Feeder with Pneumatic Releasing System
400mm Width Material Servo Roll Feeder with Pneumatic Releasing System
400mm Width Material Servo Roll Feeder with Pneumatic Releasing System
400mm Width Material Servo Roll Feeder with Pneumatic Releasing System
400mm Width Material Servo Roll Feeder with Pneumatic Releasing System
400mm Width Material Servo Roll Feeder with Pneumatic Releasing System
400mm Width Material Servo Roll Feeder with Pneumatic Releasing System
400mm Width Material Servo Roll Feeder with Pneumatic Releasing System
Specifications
Price :
$3,800/cases 1-2 cases
MOQ :
1
Payment Terms :
T/T
Supply Ability :
1set 7days
place of origin :
Guangdong, China
type :
Feeder Machine
use :
Sheet
video outgoing-inspection :
Provided
machinery test report :
Provided
core components :
PLC, Engine, Bearing, Motor
brand name :
Qiaosen
voltage :
380
power(w) :
1500
warranty :
1 Year
key selling points :
Easy To Operate
weight (kg) :
200
Feeding Speed :
15 m/min
Item name :
Pneumatic & Mechanical Feeding Straightening feeder
Keyword :
Straightening feeder
Width of material :
400mm
Thickness of material :
Max 3.2mm
Feeding capacity :
300W*2.3T
Feeding length :
0.01-9999.99mm
Roll pressure :
Spring type
Releasing system :
Pneumatic type
Pass line adjustment :
50mm
Power supply :
AC380V/3phase
Place of Origin :
China
Brand Name :
QIAOSEN
Certification :
CE / ISO14001
Description
Mechanical Precision Servo Roll Feeder
Servo Roller Feeder Punching Press Automatic Pneumatic & Mechanical Feeding Straightening feeder
400mm Width Material Servo Roll Feeder with Pneumatic Releasing System
Product Specifications
400mm Width Material Servo Roll Feeder with Pneumatic Releasing System
NC-400B NC Servo Roller Feeder
  • Feeds material for various thicknesses and feeding stroke lengths
  • Suitable for high-speed feeding and long stroke length feeding
  • Improves production capacity and feeding precision
  • User-friendly operation panel for inputting feeding length and speed
  • Feeding length range: 0.01mm - 9999.99mm
  • Adopts pneumatic cylinder releasing method, without malfunction
  • Mechanical releasing method available per customer requirements
  • High precision feeding: ±0.02mm
  • Supports 5 sets of different feeding lengths with 999 strokes each
  • Normal manual running mode with manual speed for easy material feeding
  • Effective releasing device based on press machine's cam position and material thickness
  • Touch screen input for feeding length
  • Hollow feeding roller with HRC60 surface hardness and chrome plating
Structural Features
  • High-quality servo motor for efficient feeding testing
  • High-sensitivity encoder for feedback and improved feeding precision
  • Quality belt system to avoid gear gaps, abrasion, noise, and lubrication needs
  • Internally mounted motor for protection against damage
