20FT Storage Prefabricated Luxury Flat Pack Container House
20FT Storage Prefabricated Luxury Flat Pack Container House
20FT Storage Prefabricated Luxury Flat Pack Container House
20FT Storage Prefabricated Luxury Flat Pack Container House
20FT Storage Prefabricated Luxury Flat Pack Container House
20FT Storage Prefabricated Luxury Flat Pack Container House
Specifications
Brand Name :
KXD
Model Number :
SF-00109
Certification :
CE ISO
Place of Origin :
Qingdao，China
MOQ :
1 Piece
Price :
US$1,200.00-1,500.00 1 Piece
Payment Terms :
T/T
Supply Ability :
20000ton/year
Delivery Time :
1month
Packaging Details :
pallet
Usage :
Construction
Material :
Steel
Type :
Modular
Assembly :
Efficient
Design :
Customized
Size :
Standard
Flexibility :
Versatile
Installation :
Fast
Insulation :
Energy-efficient
Transportation :
Easy
Cost :
Affordable
Weatherproof :
Resistant
Durability :
High
Sustainability :
Eco-friendly
Description

Basic Info.

Model NO.
SF-00109
Warranty
Non
Usage
Dormitories, Warehouse, Villa, Temporary Offices, Workshop
Certification
CE, ISO
Customized
Customized
Transport Package
Safe Packaging
Specification
3*6*2.8 (m)
Trademark
Sunfine
Origin
China
HS Code
9406900090
Production Capacity
50000

Product Description


Sunfine container modular house and prefabhouses that can be used as a granny flat, spare room, rental investment, first home,downsizing,deluxe mining camp accommodation, crib room, training room, office and accommodation for caravan & holiday parks, bed and breakfasts and more!
Delivery time
5-30 days
life time
20 years
MOQ
1 set
Door
930*2030Steel security d
Color
customized(white for typical)
Window
Aluminum Window/Plastic steel window
Weight
1.3T
Wall Material
50mm EPS/rockwool
Floor
1.8mm glass magnesium board

20FT Storage Prefabricated Luxury Flat Pack Container House20FT Storage Prefabricated Luxury Flat Pack Container House20FT Storage Prefabricated Luxury Flat Pack Container House20FT Storage Prefabricated Luxury Flat Pack Container House20FT Storage Prefabricated Luxury Flat Pack Container House
20FT Storage Prefabricated Luxury Flat Pack Container House20FT Storage Prefabricated Luxury Flat Pack Container House20FT Storage Prefabricated Luxury Flat Pack Container House20FT Storage Prefabricated Luxury Flat Pack Container House


Technical parameters of folding room
type
Specifications
Material name
model
thickness
Company
number
basic features
External dimension (mm)
5800*2480*2560


Internal dimension (mm)
5640*2320*2420


Folding state (mm)
5800*2480*380


Total mass (kg)

1200


Design parameters
Structural design service life
10 years


Ground live load
200kg/sqm


Roof live load

100kg/sqm


Wind load
Grade 8


seismic fortification intensity
Grade 10


frame structure
Top frame
Q235B rectangular square tube
40*80*2.44m
1.8
root
5
Q235B rectangular square tube
20*40*5.9m
1.8
root
1
Q235B rectangular square tube
80*80*5.64m
1.8
root
2
P-tube
40*80
1.8
root
2
Galvanized sheet
5.75m*1.5m
0.8
block
2
Glass wool
12m*1.5m
0.75
rice
12
Ceiling board
0.37
block
3
5.8m noodles
Q235B rectangular square tube
40*80
1.8
root
8
L-shaped steel plate (galvanized sheet)
1.165m
2
block
4
L-shaped steel plate (galvanized sheet)
1.180m
2
block
4
P-tube
40*80*5.84m
1.8
root
8
P-tube
1.05m
1.8
root
4
Hinge
High strength
1.8
individual
34
wallboard
1080*2.88m
0.3
block
8
Galvanized angle
1.08m
0.8
root
16
D-type E-type adhesive tape
5.9m
root
24
2.35m noodles
P-tube
2640
1.8
root
4
2485
1.8
root
4
2400
1.8
root
1
860
1.8
root
1
wallboard
950
0.3
rice
8.66
Galvanized angle
50#
0.8
rice
20.41
window

individual
2
Hanging head baffle

block
8
door

individual
1
Black tape

rice
21.32
Bottom frame
Custom sill
(galvanized sheet)
160*80*5.9m
2
root
2
80*80
1.8
root
2
Hinge
High strength
individual
4
C-section steel
1.8
root
14
floor
1165*2690
15mm
block
5
Angle steel
30#
root
3.5
Top of box
Integral frame coating
Electrostatic spraying / direct white plastic powder
External roof
Galvanized sheet 0.8mm
Interior ceiling
Color steel veneer V / 830 / 0.37mm
wallboard
5.8m noodles
75mm composite board 0.3mm + glass wool (unit weight: 28KG) + 0.3mm
2.48M noodles
75mm composite board 0.3mm + glass wool (unit weight: 28KG) + 0.3mm
floor
Fireproof glass magnesium floor 15mm
electrical
system
Electrical wiring, in strict accordance with the moisture-proof standard installation, all electrical products meet CE
certification. Connect the circuit according to the code of circuit engineering, indoor: incoming wire 4? GB soft copper wire, 1
20A circuit breaker, 2.5? 2 socket, 1 5-hole single opening socket, 1 5-hole socket, 1 LED lamp
anti-theft door
High quality security door (warm white) size: 960mm * 1970mm
window
920 * 920 single glass sliding window, plastic steel window, with protective fence, screen window, glass thickness of 4mm
(warmwhite)


20FT Storage Prefabricated Luxury Flat Pack Container HouseOur company offers you various kinds of steel constructions, which would meet all your requirements. Our company are professionally engaged in steel structure design,manutacture and installation. Our specialists have extensive experience in working with different type constructions. Steel constructions are manufactured by using drawing tools, in accordance with customers' all requirements and quality standards.
Our aim is highest quality, competitive price, and best service to satisfy our customers, we will always keep on creating and innovation, build a best credibility and highest reputation company in the world.
Contact me now, tell me more details about your project in your mind, let us help you to achieve it!
