Q355B Steel Frame Prefabricated Steel Building with 50-Year Durability and Seismic Resistance
Q355B Steel Frame Prefabricated Steel Building with 50-Year Durability and Seismic Resistance
Q355B Steel Frame Prefabricated Steel Building with 50-Year Durability and Seismic Resistance
Q355B Steel Frame Prefabricated Steel Building with 50-Year Durability and Seismic Resistance
Q355B Steel Frame Prefabricated Steel Building with 50-Year Durability and Seismic Resistance
Q355B Steel Frame Prefabricated Steel Building with 50-Year Durability and Seismic Resistance
Q355B Steel Frame Prefabricated Steel Building with 50-Year Durability and Seismic Resistance
Q355B Steel Frame Prefabricated Steel Building with 50-Year Durability and Seismic Resistance
Q355B Steel Frame Prefabricated Steel Building with 50-Year Durability and Seismic Resistance
Q355B Steel Frame Prefabricated Steel Building with 50-Year Durability and Seismic Resistance
Q355B Steel Frame Prefabricated Steel Building with 50-Year Durability and Seismic Resistance
Q355B Steel Frame Prefabricated Steel Building with 50-Year Durability and Seismic Resistance
Specifications
Brand Name :
KXD
Model Number :
KXD-SS56
Certification :
CE、ISO、SGS
Place of Origin :
Qingdao，China
MOQ :
500 sqm
Price :
USD 68-100 per sqm
Payment Terms :
L/C,T/T
Supply Ability :
500000 tons/month
Delivery Time :
25 days
Packaging Details :
steel pallet
Finishing Options :
Paint, Galvanization, Powder Coating
Install :
Online Guide Support & On-site Install
Color :
Custom approval
Construction Method :
Steel structure
Window :
Aluminum alloy window
Visit :
Workshop visit and check available
Description
Online Guidance Customized Structure Steel Structure Tent Prefabricated Hotel Building
Versatile Q355B Steel Frame for Heavy-Duty Industrial Steel Frame workshop and warehouse. Our steel structure warehouse and workshop buildings offer the perfect combination of durability, efficiency, and cost-effectiveness for industrial and commercial applications. Engineered with high-strength Q235B/Q355B steel, these prefabricated metal buildings deliver exceptional structural stability while maintaining a lightweight design. Ideal for manufacturing plants, distribution centers, logistics warehouses, and industrial workshops, our steel structure solutions feature rapid construction timelines, flexible large-span layouts, and superior seismic resistance.
Structural Components & Specifications
Component Specifications
Main Steel Frame Steel Columns: Q235, Q355 welded H-shaped steel
Steel Beam: Q235, Q355 welded H-shaped steel
Secondary Frame Purlin: Q235 C and Z purlins
Knee Pads: Q235 angle steel
Tie Rod: Q235 round steel pipe
Bracket: Q235 round rod
Vertical & Horizontal Supports: Q235 angle steel, round bar or steel pipe
Maintain System Roof Panels: EPS sandwich panel/glass fiber sandwich panel/Rock wool sandwich panel/polyurethane sandwich panel/steel plate
Wall Panel: Sandwich panel/corrugated steel plate
Appendix Window: Aluminum alloy windows/PVC windows/sandwich panel windows
Door: Sliding sandwich panel door/rolling metal door
Awning: PVC
Performance Specifications
  • Live Load on Roof: 120kg/m² (surrounded by colored steel plates)
  • Wind Resistance Level: 12 levels
  • Earthquake Resistant: 8 levels
  • Structure Usage: Up to 50 years
  • Organizing Options: Wide variety of colors and textures available
Certifications & Standards
ISO 9001 CE SGS AWS D1.1
Welding Standard Service: Design + Fabrication + Installation + 10-year warranty
Paint Options: Three layers of anti-rust paint (epoxy zinc-rich primer, epoxy micaceous iron intermediate paint, and polyurethane topcoat) or galvanized
Manufacturing Capabilities
Our facility operates 170 sets of advanced fabrication equipment, including large hydraulic press brakes, CNC drilling machines, China's largest shot blasting units, and ultrasonic flaw detectors, ensuring precision manufacturing standards.
Cost-Effective & Economically Practical
From initial investment to long-term operation, steel structure warehouses offer superior cost efficiency. Lower material and foundation costs, minimal maintenance, and fast construction all lead to substantial savings over the building's entire lifecycle.
Q355B Steel Frame Prefabricated Steel Building with 50-Year Durability and Seismic Resistance
Sustainable & Fully Recyclable Materials
Our structures are built with eco-friendly steel that is 100% recyclable, greatly reducing environmental impact. The clean, dry construction process produces almost no waste. At the end of service life, all materials can be fully recycled, helping you achieve your corporate sustainability targets.
Q355B Steel Frame Prefabricated Steel Building with 50-Year Durability and Seismic Resistance
Simple Maintenance & Easy Installation
Pre-engineered components with bolted connections make installation and future maintenance highly efficient. Corrosion-resistant steel ensures low upkeep, and modular panels can be quickly replaced, minimizing downtime and maintenance costs.
Q355B Steel Frame Prefabricated Steel Building with 50-Year Durability and Seismic Resistance
Extended Service Life & Long-Term Durability
Featuring premium materials and professional anti-corrosion treatment, our steel structures provide 50+ years of reliable service. Weather-resistant coatings and galvanized components effectively prevent rust, UV damage and environmental degradation, ensuring long-term structural stability.
Q355B Steel Frame Prefabricated Steel Building with 50-Year Durability and Seismic Resistance
