Stainless Special Elliptical Steel Tubing Tp409 Welded Seamless For Auto Industries
Stainless Special Elliptical Steel Tubing Tp409 Welded Seamless For Auto Industries
Stainless Special Elliptical Steel Tubing Tp409 Welded Seamless For Auto Industries
Stainless Special Elliptical Steel Tubing Tp409 Welded Seamless For Auto Industries
Stainless Special Elliptical Steel Tubing Tp409 Welded Seamless For Auto Industries
Stainless Special Elliptical Steel Tubing Tp409 Welded Seamless For Auto Industries
Stainless Special Elliptical Steel Tubing Tp409 Welded Seamless For Auto Industries
Stainless Special Elliptical Steel Tubing Tp409 Welded Seamless For Auto Industries
Specifications
Characteristic :
Stainless Special Elliptical Steel Tube
Material :
TP409, 304, 304L, 316, 316L etc
Production Method :
Seamless or welded
Package :
In bundles or as per requests
End protector :
Plain / Beveled
Length :
2-12m
Type :
Elliptical Steel Tube
MTC :
EN10204.3.1
Brand Name :
Torich
Model Number :
TP409 etc
Certification :
ISO 9001 ISO14001 TS16949
Place of Origin :
China
MOQ :
1 tons
Price :
negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union,
Supply Ability :
30000 Ton per Year
Delivery Time :
30-45 days after order confirmed
Packaging Details :
In plywood case, In wooden box.
Description

Products Description:

Elliptical Welded Seamless Stainless Special Steel Tube TP409 For Auto Industries

Steel Grade/Steel Material:

Mechanical Requirement
Grade: TP304 TP304L TP304LN TP316 TP316L TP316LN TP316LN TPXM-29 TP304N
UNS S30400 S30403 S30453 S31600 S31603 S31653 S31653 S24000 S30451
C, max 0.08 0.035 0.035 0.080 0.035 0.035 0.035 0.08 0.080
Mn, max 2.00 2.00 2.00 2.00 2.00 2.00 2.00 11.5-14.5 2.00
P, max 0.045 0.045 0.045 0.045 0.045 0.045 0.045 0.060 0.045
S, max 0.030 0.030 0.030 0.030 0.030 0.030 0.030 0.030 0.030
Si, max 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00
Ni 18.0-20.0 18.0-20.0 18.0-20.0 16.0-18.0 16.0-18.0 16.0-18.0 16.0-18.0 17.0-19.0 18.0-20.0
Cr 8.0-11.0 8.0-13.0 8.0-12.0 11.0-14.0 10.0-14.0 11.0-14.0 11.0-14.0 2.3-3.7 8.0-18.0
Mo … … … 2.00-3.00 2.00-3.00 2.00-3.00 2.00-3.00 … …
Nitrogen … … … … … … … … …
Copper … … … … …


Delivery Condition:

Pickled and Annealed, or as customer's requirement

Size Range:

OD: 8-100mm*6-70mm

WT: 1-8mm

Length: max 12000mm

Characteristic:

Good concentricity

Good OD and ID tolerance

High Precision

Stable quality

Smooth Roughness

TORICH QUALITY ASSURANCE

Production Processs:

The tubes shall be made from flat-rolled steel by an automatic welding process with no addition of the filler metal----cold drawn to oval shape tube----cut to the required length----deburr

Production Steel Tube:

Stainless Special Elliptical Steel Tubing Tp409 Welded Seamless For Auto Industries

Stainless Special Elliptical Steel Tubing Tp409 Welded Seamless For Auto Industries

Eddy Current Test and Ultrasonic Test:

Stainless Special Elliptical Steel Tubing Tp409 Welded Seamless For Auto Industries

Packing:

Stainless Special Elliptical Steel Tubing Tp409 Welded Seamless For Auto Industries
