Specifications
Brand Name :
TORICH
Model Number :
Internal Hex Tubing
Certification :
ISO9001 ISO 14001 TS16949
Place of Origin :
Zhejiang/China
MOQ :
1Ton
Price :
800-1200 USD/Tom
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
60000 Ton/Tons per Year
Delivery Time :
20-30days upon products
Packaging Details :
In bundles or in wooden boxes.
Application :
Structure Pipe,Hydraulic Pipe,Construction,Fluid Pipe,Oil Pipe
Outer diameter(round) :
30 - 426 mm,
Thickness :
2 - 100 mm
Standard :
ASTM,DIN,GB,JIS,API
Technique :
Cold Drawn,Hot Rolled,Cold Rolled,ERW,Hot Rolled/Cold Drawn
Grade :
SAE1010, SAE1020, SAE1035, SAE1045, ST37.0, ST44, ST52,
Section shape :
Round,Rectangular
Length :
6M or as requirement,As customer's require
Description


SAE 1010 Carbon Steel Seamless Pipe 30-426mm OD for Machine Engineering

SAE 1010 Carbon Steel Seamless Tubing for Machine Engineering

Material

This series of seamless pipes is made from high-quality carbon steel grades, including SAE 1010, SAE 1020, SAE 1035, ST37, and E235. These materials are designed to offer excellent mechanical properties, durability, and corrosion resistance, making them suitable for various machine engineering applications.

Specifications

  • Product Type: Carbon Steel Seamless Pipe

  • Material Grades: SAE 1010, SAE 1020, SAE 1035, ST37, E235

  • Shape: Round, or special shapes upon request

  • Standard: Custom-made to meet specific machine engineering requirements

Chemical Composition

Grade Carbon (C) Manganese (Mn) Phosphorus (P) Sulfur (S) Silicon (Si)
SAE 1010 0.08 - 0.13 0.30 - 0.60 ≤ 0.040 ≤ 0.050 ≤ 0.30
SAE 1020 0.18 - 0.23 0.30 - 0.60 ≤ 0.040 ≤ 0.050 ≤ 0.35
SAE 1035 0.32 - 0.38 0.60 - 0.90 ≤ 0.035 ≤ 0.040 ≤ 0.30
ST37 0.12 - 0.20 0.30 - 0.60 ≤ 0.040 ≤ 0.035 ≤ 0.30
E235 0.10 - 0.20 0.30 - 0.60 ≤ 0.035 ≤ 0.035 ≤ 0.30

Mechanical Properties

Property SAE 1010 SAE 1020 SAE 1035 ST37 E235
Yield Strength ≥ 220 MPa ≥ 250 MPa ≥ 320 MPa ≥ 235 MPa ≥ 235 MPa
Tensile Strength ≥ 410 MPa ≥ 450 MPa ≥ 490 MPa ≥ 370 MPa ≥ 430 MPa
Elongation ≥ 25% ≥ 20% ≥ 20% ≥ 25% ≥ 20%
Hardness (HB) ≤ 140 ≤ 160 ≤ 170 ≤ 150 ≤ 155

Main Features

  • Seamless Construction: Manufactured using advanced seamless technology, ensuring high strength and reliability.

  • Variety of Grades: Includes SAE 1010, SAE 1020, SAE 1035, ST37, and E235 to cater to various engineering and mechanical requirements.

  • Corrosion Resistance: The pipes offer excellent resistance to corrosion and oxidation, extending their lifespan and performance.

  • Custom Shapes: Available in special shapes as per customer requirements, including internal and external profiles.

Standards

  • SAE 1010: ASTM A108, SAE J403

  • SAE 1020: ASTM A108, SAE J403

  • SAE 1035: ASTM A108, SAE J403

  • ST37: DIN 17100, EN 10025

  • E235: EN 10305-1, EN 10210

Applications

  • Machine Engineering: Ideal for various mechanical components requiring strong, durable, and precise pipes, including hydraulic and fluid transmission systems.

  • Automotive Industry: Used in automotive applications that require high-strength pipes for critical components such as fuel lines and suspension systems.

  • Structural Engineering: Suitable for structural components needing high impact resistance and precise geometries.

  • Hydraulic and Pneumatic Systems: Perfect for use in systems that demand precise pressure management and fluid flow control.


SAE 1010 Carbon Steel Seamless Pipe 30-426mm OD for Machine Engineering

SAE 1010 Carbon Steel Seamless Pipe 30-426mm OD for Machine Engineering SAE 1010 Carbon Steel Seamless Pipe 30-426mm OD for Machine Engineering


SAE 1010 Carbon Steel Seamless Pipe 30-426mm OD for Machine Engineering SAE 1010 Carbon Steel Seamless Pipe 30-426mm OD for Machine Engineering


SAE 1010 Carbon Steel Seamless Pipe 30-426mm OD for Machine Engineering

SAE 1010 Carbon Steel Seamless Pipe 30-426mm OD for Machine Engineering

SAE 1010 Carbon Steel Seamless Pipe 30-426mm OD for Machine Engineering

SAE 1010 Carbon Steel Seamless Pipe 30-426mm OD for Machine Engineering

SAE 1010 Carbon Steel Seamless Pipe 30-426mm OD for Machine Engineering

Q: Are you trading company or manufacturer ?

A: manufacturer,also can do trading.


Q: How long is your delivery time?

A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock,

it is according to quantity.


Q: Do you provide samples? is it free or extra ?

A: Yes, we could offer the sample for free charge but need pay the cost of freight.


Q: What is your terms of payment ?

A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.

If you have another question, pls feel free to contact with me.
