Specifications
Place of Origin :
Beijing, China
Brand Name :
Huaxin
Model Number :
HS602
Generated pressure range :
-0.1-0/0-2500bar
Accuracy :
+/-0.025% F.S;+/-0.05%F.S
Working media :
Air;oil; water
Body material :
Stainless steel/Aluminum alloy
Connection :
M20*1.5Female
Weight :
0.75KG
Dimension :
95L x 50W x 166H (mm)
Name :
HS602 Intelligent Pressure Gauge/Indicator
Packaging Details :
Plywood Carton
Port :
Beijing Airport
Supply Ability :
5000 Piece/Pieces per Year
Price :
$800.00 - $2,000.00/pieces
MOQ :
1 unit
Description

Product Description
HS602 Intelligent Pressure Calibrator has the double-line large screen with backlight function. It can meet customers' requirement in the 6-digit display and 9 pressure units. It provides pressure measurement for calibrating pressure (differential pressure) transmitters, precision (general) pressure gauges and other pressure instruments. It has been used in the industries of power, chemical, petrol, metallurgy, metering, etc.

Technical specification

Range(-1-0)bar,(0-2500)bar(any range within this two range)
Accuracy:±0.025%F.S,±0.05%F.S,±0.1%F.S,±0.2%F.S,±0.5%F.S
Current measurement: (0-25)mA
Accuracy:±(0.02%R.D+0.005%F.S)
Voltage measurement: (0-25)V
Accuracy:±(0.02%R.D+0.005%F.S)
Temperature compensating range:(0-50)℃
DC output:DC24V(≤30mA) Accuracy: ±1%F.S
Power supply:7.4Vdc Lithium battery power supply and special charger
Connection:M20×1.5 or 1/4"NPT male thread(or customized)
Dimensions:Φ95mmx49mm. Total Height:166mm
Weight:0.75kg

Features
Equipped with rugged ABS plastic
Pressure-transmitting medium including air, oil, and water
6-digit LCD screen with backlight
Nine Pressure Units Selectable: kPa, Pa, psi, kgf/cm2, bar, mbar,mmH2O, mmHg, MPa
Zero point, full scale calibration function
7.4Vdc Lithium battery and special charger
Overload and short circuit protection
Light weight, small size, easy operation
Rapid in operation, compatible with computer software
Support Hart Version 5
With max/min Values functions
CE&EX approved

Stainless Steel Bottomessure and ABS Plastic Cover HS602 Digital Pressure Calibrator GaugeStainless Steel Bottomessure and ABS Plastic Cover HS602 Digital Pressure Calibrator Gauge

Stainless Steel Bottomessure and ABS Plastic Cover HS602 Digital Pressure Calibrator Gauge

Packaging & Shipping

Packaging Details: Plywood carton
Delivery Detail: 3~7 working days upon receipt of deposit

Company Information

HUAXIN INSTRUMENT (BEIJING) CO., LTD. is a highly reputed organization dedicated to manufacturing in calibration and metering field.Having specialized in this field for more than ten years. During considerable development, our products have already been widely used in the industries of power, chemical, petrol, metallurgy, metering, etc and currently used in over 40countries and have a lot of agents worldwide .Based on excellent performance,we have joined in setting industry standard for product sfety ,operability,durability and reliability in China, Also CE,EX.ISO9001 and HART are approved.

Stainless Steel Bottomessure and ABS Plastic Cover HS602 Digital Pressure Calibrator Gauge

HUAXIN INSTRUMENT(BEIJING)CO.,LTD.
Add:Yilan Building,Huoju St,Changping Dist, Beijing,102200,China
Tel: +86-10-62392087 Fax: +86-10-62345183
Web: www.sino-instruments.com
