Aluminum Alloy Tomarukun Vehicle Security Barriers
Aluminum Alloy Tomarukun Vehicle Security Barriers
Specifications
Brand Name :
RMHs
Model Number :
TOMARUKUN
Place of Origin :
CHINA
Payment Terms :
L/C,T/T
Supply Ability :
400PCSper1 month
Delivery Time :
30
Packaging Details :
Carton packing 208pcs 40-inch containers
Material :
Aluminum alloy rubber sheet
Color :
Traffic orange
Function :
intercept vehicle/shortening the impact distance
Treatment technology :
Bending + welding
Placement :
Periphery of construction area
Weight :
25KG
Description

Light weight easy to move crash barrier Vehicle Security Barriers


The Small Vehicle Interception Device (Model: TOMARUKUN) is a movable isolation warning barrier designed specifically for construction zones on municipal roads. With its eye-catching appearance and controlled interception structure, it effectively warns and intercepts low‑speed vehicles that mistakenly enter the area, ensuring the safety of construction personnel and drivers.

Aluminum Alloy Tomarukun Vehicle Security Barriers

Product Specifications



Item Specifications
Brand RMHs
Model TOMARUKUN
Weight 25 kg
Material Aluminum, Rubber
Color Yellow/Orange (traffic warning colors)
Dimensions W320mm × L1070mm × H860mm
Structure Foldable, with wheels
Surface Finish Electrostatic spraying
Manufacturing Process Welding, Bending
Applicable Scope Municipal roads, construction areas, low‑speed vehicle passages


Working principle: When a vehicle hits the device, the elbow part at the front of the device will drive the front wheels of the car to lift up, causing the wheels to leave the ground, and the vehicle loses its forward momentum and transfers to the ground. As the rubber at the bottom of the device is under force, the friction between the rubber and the ground increases, forcing the vehicle to stop.




In order to increase the friction and facilitate the movement, we designed and installed rubber blocks and rubber wheels at the bottom of the product.


Product Advantages

  1. Safe and Reliable – Passed collision tests by a Japanese automotive laboratory; provides controlled interception to effectively protect personnel safety.

  2. High Visibility – Eye-catching traffic yellow color, can be paired with LED indicator boards to enhance all-weather warning effectiveness.

  3. Lightweight and Flexible – Weighs only 25kg; foldable design with wheels, allowing one person to move, install, and store it easily.

  4. Durable and Sturdy – Made of environmentally friendly aluminum with electrostatic coating, rust-resistant and weather-resistant, suitable for long-term outdoor use.

  5. Quick Deployment – Modular design allows rapid setup without tools, suitable for various construction scenarios.

  6. Eco-Friendly and Cost-Effective – Recyclable and non-flammable materials reduce secondary hazards and lower long-term operating costs.

Small Vehicle Interception Device (RMHs TOMARUKUN) vs. Traditional Traffic Cones / Water-Filled Barriers



Comparison Dimension RMHs TOMARUKUN Traditional Traffic Cones / Water-Filled Barriers
Core Function Active Interception: Stops vehicles through controlled collision, providing physical protection. Passive Warning: Only serves as a visual reminder and route guide; no interception capability.
Safety Level High: Certified via crash testing; effectively absorbs impact energy to protect personnel and vehicles. Low: Prone to scattering upon impact, potentially causing secondary harm; suitable only for warning purposes.
Deployment Efficiency High: Single-person operation, foldable with wheels for fast modular deployment and retrieval. Medium/Low: Traffic cones require individual placement/retrieval; water-filled barriers are heavy and time-consuming to move and set up.
Durability & Maintenance High: Aluminum body with electrostatic coating, corrosion and rust-resistant, long service life, low maintenance cost. Low: Plastic fades and degrades easily; rubber is prone to damage, requiring frequent replacement and higher long-term costs.
Visibility & Warning Strong: Large-area bright yellow surface, can be integrated with LED indicator boards, highly visible day/night and in poor weather. Weak: Relies on reflective strips; effectiveness decreases significantly in rain, fog, night, or bright light.
Applicable Scenarios Professional Protection Scenarios:
• Municipal road construction zones
• Long-term maintenance areas
• Roads requiring active interception (vehicle speed ≤60 km/h)		 Basic Warning Scenarios:
• Temporary lane closures
• Traffic flow guidance
• Low-risk, short-term work zones
Overall Cost Higher upfront investment, higher long-term value.
Advantages: One-time investment, durable, low maintenance, reduces potential accident losses.		 Lower unit cost initially, higher long-term total cost.
Disadvantages: Prone to wear, requires frequent replacement, weak accident protection capability.

Summary:
The RMHs TOMARUKUN is an active safety protection device with irreplaceable advantages in medium-to-high risk construction areas requiring substantial physical interception. While its initial investment is higher than traditional traffic cones, it outperforms in safety, efficiency, durability, and long-term cost, making it a professional choice for upgrading modern road construction safety.


Aluminum Alloy Tomarukun Vehicle Security Barriers

Product Q&A: RMHs TOMARUKUN Aluminum Alloy Vehicle Security Barrier

Q1: What are the core advantages of this product?
A: It is made of high-quality aluminum alloy with strict quality control, featuring active collision interception capability, a foldable and mobile design, and high-visibility warning properties, specifically optimized for safety protection in municipal road construction.

Q2: Why choose aluminum alloy material?
A: Aluminum alloy is lightweight yet strong, corrosion-resistant, and environmentally recyclable. Combined with electrostatic spraying, it ensures long-term outdoor use without rusting, meeting both safety and sustainability requirements.

Q3: Is the product safety certified?
A: Yes, the product has passed collision tests conducted by a Japanese automotive laboratory, verifying its controlled interception performance and safety in low-speed collision scenarios. Relevant test videos are available for reference.

Q4: What scenarios is it suitable for?
A: It is mainly used in municipal roads, maintenance work zones, and low-speed vehicle areas (≤60 km/h). It can be deployed individually or in combination and can be paired with LED indicator boards to enhance warning effectiveness.

Q5: Is deployment and storage convenient?
A: Highly convenient. The product weighs only 25 kg, features a foldable design, and is equipped with wheels at the bottom, allowing for quick deployment, movement, and storage by a single person without tools.

Q6: Can it be used on highways?
A: This product is designed for low-speed scenarios (≤60 km/h). For use on highways or national roads, it is recommended to deploy multiple units in groups 50–100 meters behind the work zone, strictly adhering to local traffic regulations.

Q7: How is product quality ensured?
A: The product comes from China's leading Tomarukun vehicle security barrier production base. The factory strictly implements a quality management system, controlling the entire process from raw materials to finished products to ensure each batch meets high-performance standards.

Q8: Is customization supported?
A: Limited customization is available for size, color, and logo printing, subject to further discussion based on specific needs. Standardized products already cover most application scenarios.

Q9: What is the product's service life?
A: Under normal usage conditions, the aluminum alloy main structure can last over 10 years, with the surface coating being wear-resistant and weather-resistant, maintaining long-term warning effectiveness.

Q10: How can I obtain more information or test reports?
A: Please feel free to contact us for detailed technical specifications, test videos, and compliance documents. We can also arrange sample trials or on-site demonstrations.


































品牌:RMHs 重量:25KG 材质:铝材,橡胶 型号:TOMARUKUN 表面工艺:静电喷涂 适用范围:市政道路隔离警示栏 颜色:黄色/橘黄色 尺寸:W320mm*L1070*H860mm 结构:可折叠,带车轮 制作工艺；焊接,折弯 "小型汽车拦截装置主要适用于车辆低速行驶的市政道路,可搭配悬挂LED导光板指示,设置于施工现场的外围.产品醒目的外观可以起到警示作用,如司机驾驶不当或误入施工禁地时,行驶车辆能通过撞击该产品,以可控的方式使撞击车辆停止,一定程度上保护司机和现场施工人员的生命安全,警示和拦截作用明显. 小型主要由环保铝材折弯,焊接而成,材料具有不易燃性,在发生碰撞事故后,可减少次生灾害.产品结构合理,重量为25kg,可折叠的设计,收放轻松,底部两侧安装了万向轮,可便捷高效的完成移动部署工作." "Product Description The small car interception device is mainly suitable for municipal roads where vehicles are driving at low speeds. It can be equipped with a suspended LED light guide plate to indicate and set up on the periphery of the construction site. The eye-catching appearance of the product can serve as a warning. When the driver drives improperly or enters the forbidden construction site by mistake, the driving vehicle can hit the product to stop the impacting vehicle in a controlled manner to protect the life of the driver and on-site construction personnel. The warning and interception functions are obvious. Tomarukun is mainly made of environmentally-friendly aluminum by bending and welding. The material is non-flammable and can reduce secondary disasters after a collision. The product has a reasonable structure, weighs 25kg, and has a foldable design that can be easily retracted and unfolded. Universal wheels are installed on both sides of the bottom to complete the mobile deployment work conveniently and efficiently." 产品适用于车辆低速行驶的施工地段,如市政道路维修,市政道路养护等路段. "Scope of application The product is suitable for construction sites where vehicles are traveling at low speeds, such as municipal road maintenance, municipal road maintenance and other road sections." "1. 精选吸收铝材,环保,可回收,质量安全可靠 2.外部静电喷涂工艺,不易生锈,适合室外天气条件 3.高亮醒目交通黄,可以搭配我司的LED箭头板使用,警示作用明显 4.配备可移动便捷车轮,方便移动,易于开展模块化部署工作 5.产品可折叠的设计,易于运输和储存 6.重量轻,结构设计合理,单人可完成安装,拆卸,收纳的工作." "Product advantages 1. Environmentally-friendly absorption aluminum material, recyclable, safe and reliable in quality. 2. The external electrostatic spraying process is not easy to rust and is suitable for outdoor weather conditions. 3. The bright and eye-catching traffic yellow can be used with our LED arrow board, which has obvious warning effect. 4. Equipped with movable and convenient wheels, convenient to move and easy to carry out modular deployment. 5. The product is foldable design, easy to transport and store. 6. Light weight, reasonable structure design, single person can complete the work of installation, disassembly and storage." 该产品已通过日本汽车实验室测试,详见测试视频. "Test This product has passed the test of Japanese automobile laboratory, please refer to the test video." "设置方法一:市内行驶速度≤60KM/H ,设置于施工道路前后方各10米处,一般2台为一组,可视道路情况增加数量,可配合方向指示板或者禁止进入标牌使用. 设置方式二:高速国道等车辆行驶速度较快的路段, 设置于施工路段后方50-100米位置,3台为一组,每台的间距为10米,具体使用数量视施工路段具体而定." 产品的简单描述 产品的规格表 简单

翻译

产品的优势 简单

翻译

简单优势对比

翻译
