Large portable and retractable Highway Crash Attenuator

The motor tractor fixed on the rear of the maintenance vehicle, the exterior is electrostatically sprayed. The yellow body is matched with red and white reflective warning strips, and equipped with a retractable LED arrow board, which the warning effect very obvious. The internal special aluminum structure can absorb the impact force through deformation, and can be easily repaired if the deformation is not serious.

Product Specifications

• Brand/Model: RMHs / QYC
• Material: Steel, Aluminum
• Color: Yellow / Orange-yellow
• Surface Finish: Electrostatic Spraying
• Weight: 129KG
• Structure: Liftable (equipped with bottom wheels for easy movement)
• Functions: Warning and traffic guidance (reflective film + LED arrow board + warning buzzer light); impact energy absorption
• Scope of Application: Rear of construction vehicles (temporary road safety maintenance)
• Customization Service: Customizable dimensions, OEM processing as per provided drawings

Structural drawing of the product

Advantages of RMHs Truck Mounted Attenuator

1. Dual Safeguards for Protection




   Built-in impact energy absorption packages and a special aluminum shock-absorbing structure can efficiently absorb the impact force of rear-end collisions, significantly reduce accident damage, and fully protect the safety of people and vehicles in the construction operation area.
2. Highly Visible Warning Effect




   The yellow electrostatically sprayed main body is matched with red-white warning strips, equipped with high-brightness LED arrow boards, reflective films and top warning buzzer lights. It can clearly alert rear vehicles even in low-visibility environments, achieving excellent warning and traffic guidance effects.
3. Flexible, Convenient and Easy to Operate
   • Liftable structure: The arrow board can be retracted when not in use to save storage space.
   • Easy mobility: With bottom wheels, it can be fixed at the rear of construction vehicles and moved along with them, ideal for temporary road maintenance scenarios.
   • Adjustable arrow direction: The LED arrow direction can be freely switched to meet the needs of different construction traffic guidance.
4. Low Maintenance Cost




   After slight collision deformation, there is no need to replace the entire device. The repair can be easily completed by only replacing the internal absorption materials, effectively reducing the later maintenance cost.
5. Strong Adaptability with Customization Service




   It supports customized dimensions and OEM processing according to provided drawings, and can flexibly adjust product specifications to meet the needs of different customers' construction vehicles and application scenarios.

Q&A

1. Q: What kind of equipment is this? Where is it used?




   A: A truck-mounted collision cushion device. It is installed at the rear of construction vehicles for safety protection during temporary road maintenance operations.
2. Q: What is its core working principle?




   A: It relies on built-in energy absorption packages and an aluminum shock-absorbing structure to absorb impact force during collisions, protecting people and vehicles.
3. Q: How is the warning effect?




   A: With yellow spraying, red-white warning strips, LED arrows, reflective film and buzzer lights, it provides clear warnings even in low-visibility conditions.
4. Q: Is it easy to use and store?




   A: The arrow board is liftable for storage, with bottom wheels for vehicle-mounted mobility. The steel-aluminum material ensures it is lightweight and easy to install.
5. Q: How to repair it after collision? Is the cost high?




   A: Only internal absorption materials need to be replaced after minor collisions, without replacing the entire device, resulting in low maintenance costs.
6. Q: Can it fit different vehicles?




   A: Yes. It supports customized dimensions and OEM processing to fit various construction vehicles.
