Specifications
Brand Name :
HUAN NENG
Model Number :
HN190F
Certification :
CE,ISO,ISO9001
Place of Origin :
Chongqing, China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
20000 sets per month
Delivery Time :
7-15 work days
Packaging Details :
Carton box packing for each set
Cold style :
Force Air-cooled
Condition :
Totally New
Warranty :
1 Year or more
Usage :
Automobile,water pump,generator
Color :
As your choice
Description

HN190F Single-Cylinder Four Stroke Diesel Engine Quiet No Disturbing

Air-Cooled Diesel Engine

Advantage,
1. Lightweight design, compact effect, high output power in the same volume, can meet a variety of applications
2. Process innovation, long service life, we continue to innovate in process details, high strength, low vibration, good wear resistance, make the engine run more smoothly.

The Details of this diesel engine

型号 Model 152F/P 154F/P 168FA/P 168FB/P 170F/P 173F/P 177F/P 182FA/P 188F/P 190F/P
形式 Form 单缶I,四冲程,强制风冷 Single cylinder, four stroke, forced air cooling
点火方式 Lgnilion mode 无fti点晶体管电子点火 Contactless transistor electronic ignition
起动方式 Starting mode 回屋式手拉起动 Recovery manual start
油耗(g/kw-h) Fuel consumption (g/kW-h) w450 W420 <395 w395 w374 w374 W374 W374 W374 w374
缸径/行程(mm ) Bore / stroke (mm) 52x46 54x38 68x45 68x45 70x45 73x58 77x58 82x64 88x64 90x66
活塞排at (ml) Piston displacement (ML) 98 87 163 196 215 242 270 338 389 420
最大功率/5专速 (Kw/rpm) Maxirmim pov/er/speed 1.15/3600 1.15/3600 3.2/3600 3.8/3600 4.0/3600 4.2/3600 4.6/3600 6.1/3600 7.2/3600 8.1/3600
最大扭矩 (N-m/rpm) 岬漸" 2.5/2600 3.0/2600 8.8/2600 10.2/2600 12/2600 13/2600 14/2600 19/2500 21/2500 23/2500
净重(kg) Net weight (kg) 8.8 10 18 18 18 25 25 31 31 32
外形尺寸[mm] Boun^r^in^nsion [mm](L xWx H) 280x270x345 280x270x345 350x315x335 350x315x335 350x315x335 495x430x505 495x430x505 495x430x505 495x430x505 495x430x505
