Low Noise NdFeB Gasoline Welding Generator Machine 4.5KW
Low Noise NdFeB Gasoline Welding Generator Machine 4.5KW
Low Noise NdFeB Gasoline Welding Generator Machine 4.5KW
Low Noise NdFeB Gasoline Welding Generator Machine 4.5KW
Low Noise NdFeB Gasoline Welding Generator Machine 4.5KW
Low Noise NdFeB Gasoline Welding Generator Machine 4.5KW
Low Noise NdFeB Gasoline Welding Generator Machine 4.5KW
Low Noise NdFeB Gasoline Welding Generator Machine 4.5KW
Low Noise NdFeB Gasoline Welding Generator Machine 4.5KW
Low Noise NdFeB Gasoline Welding Generator Machine 4.5KW
Specifications
Brand Name :
HUAN NENG
Model Number :
AXQ-210A
Certification :
CE, ISO 14001, ISO 9001
Place of Origin :
Chongqing, China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
20000 sets per month
Delivery Time :
7-15 work days
Packaging Details :
Carton box packing for each set
Warranty :
1 Year or 365days
Automatic grade :
Automatic,
Condition :
Completely New
Color :
As customer's requirement
Origin :
Made in China ChongQing
rated voltage :
220v/230v/As customer's requirement
Description

AXQ-210A Low Noise Rated 5kw Single-Phase Manual/Electric start Gasoline Integrated Power Generation And Welding Machine

5kw Integrated Power Generation And Welding Machine

Advantage and warning:

The all-in-one gasoline welding generator solves the problem of lack of energy source for on-site welding. It is equipped with a 170 motor, made of rare earth permanent magnet material NdFeB. If you want more power, you can choose a larger model. In addition, the table is equipped with a 2KW low power supply, DC 220V and the output can be equipped with carbon brush power tools and incandescent lamps. Note: Do not use inductive loads (such as transformers, electric fans, AC motors, household appliances, etc.)

The details of it:

Unit brand model Huaneng Power 6000KI-GW230
dynamo Excitation method AVR voltage automatic adjustment
Rated output power 4.5KW
maximum output power 5KW
Rated voltage 220V
Maximum current 19.6A
Rated frequency 50Hz
Phase Simplex
Power factor COSΦ 1
Insulation class Class F
engine engine model 172F
Bore*stroke 72*55mm
Displacement 212cc
fuel consumption rate ≤135g/KW.h
ignition method Transistor contactless ignition
engine type single cylinder four stroke forced air cooling
fuel type ≥90# unleaded gasoline
oil quantity 0.6L
Start method hand start
Welding parameters Welder method hand arc welding
No-load voltage VDC 70V
Welding rod diameter mm 2.0-4.0
Current adjustment range 20-230A
Rated voltage VDC 22-28V
load duration >60%
Affiliate configuration fuel volume 15L
oil alarm Have
fuel indicator Have
control panel digital display
other noise 75dBA/7m
Continuous working time 8h
Dimensions 500*425*530mm
Package rigid carton
weight 37kg
