Polcd Colorful 3.5 inch 320x480 Color Capacitive Touch IPS Viewing Angle TFT-LCD Panel Modules
Polcd Colorful 3.5 inch 320x480 Color Capacitive Touch IPS Viewing Angle TFT-LCD Panel Modules
Polcd Colorful 3.5 inch 320x480 Color Capacitive Touch IPS Viewing Angle TFT-LCD Panel Modules
Polcd Colorful 3.5 inch 320x480 Color Capacitive Touch IPS Viewing Angle TFT-LCD Panel Modules
Polcd Colorful 3.5 inch 320x480 Color Capacitive Touch IPS Viewing Angle TFT-LCD Panel Modules
Polcd Colorful 3.5 inch 320x480 Color Capacitive Touch IPS Viewing Angle TFT-LCD Panel Modules
Polcd Colorful 3.5 inch 320x480 Color Capacitive Touch IPS Viewing Angle TFT-LCD Panel Modules
Polcd Colorful 3.5 inch 320x480 Color Capacitive Touch IPS Viewing Angle TFT-LCD Panel Modules
Specifications
Display area :
48.96(H)x73.44(V)mm
Model Number :
P035M068-IPS
Payment Terms :
T/T,L/C,Credit card,PayPal,D/A,D/P,Western Union,MoneyGram
Viewing Direction(eye) :
IPS
Certification :
RoHS, ISO9001
Place of Origin :
Shenzhen, China
Driver IC :
ILI9488
Resolution :
3.5 inch 320x480
Interface :
18BIT RGB
Brand Name :
Polcd
Delivery Time :
1-7 working days
Price :
Please contact us for latest price
Supply Ability :
40,000 PCS per day
Packaging Details :
FCL size: 40*30*20cm / Sample Packaging: 20*18*13cm
Brightness (cd/m²) :
300 nit
MOQ :
1 piece
Description

Technical Parameters:

Model No. P035M068-IPS
Screen Size 3.5 inch
Number of Pixel 320RGB(H)x480(V)
Pin 40 pin
Display area 48.96(H)x73.44(V)mm
Pixel pitch 51(H)x153(V)um
Outline Dimension 54.50x84.71x2.10mm
Pixel arrangement RGB Vertical Stripe
Display mode Normally Black
Viewing Direction(eye) ALL
Display Color 262K
Luminance(cd/m2) 300 nit
Contrast Ratio 700:1
Interface 18BIT RGB
Back-light LED Side-light type
Drive IC ILI9488
Operation Temperature -20~70 ℃
Storage Temperature -30~80 ℃


Application

A 3.5 inch TFT LCD can be used in a variety of applications, including:

Portable electronic devices: A 3.5 inch TFT LCD is commonly used in portable electronic devices such as digital cameras, handheld gaming devices, portable media players, and GPS devices.

Industrial equipment: TFT LCDs are commonly used in industrial equipment such as test and measurement instruments, process control systems, and machine vision systems.

Medical devices: TFT LCDs are used in various medical devices such as patient monitoring systems, ultrasound machines, and medical imaging equipment.

Automotive applications: TFT LCDs are used in automotive applications such as dashboard displays, rearview cameras, and infotainment systems.

Consumer electronics: TFT LCDs are used in a variety of consumer electronics such as smartphones, tablets, and smartwatches.
