Description:
A 10.1-inch TFT LCD is a high-quality display screen commonly used in tablets, laptops, and monitors. It offers vibrant colors and a clear viewing experience with a compact size that is ideal for portable devices.
Parameter:
| Model | P10150UX-V01 |
| Screen Size | 10.1 inch |
| Number of Pixel | 1024RGB(H)x600(V) |
| Pin | 50 pin |
| Display area | 222.72(H)x125.28(V) mm |
| Pixel pitch | 0.0641(H)x0.1784(V) mm |
| Outline Dimension | 235.00x143.00x6.55 mm |
| Pixel arrangement | RGB Vertical Stripe |
| Display mode | Normally White |
| Viewing Direction(eye) | 6 o'clock |
| Display Color | 262k |
| Luminance(cd/m2) | 260 nit |
| Contrast Ratio | 500:1 |
| Interface | RGB 24bit |
| Back-light | LED Side-light type |
| Drive IC | EK79001 |
| Operation Temperature | -20~70℃ |
| Storage Temperature | -30~80℃ |
