Specifications
Brand Name :
Polcd
Model Number :
P028B123P-10-IPS
Certification :
RoHS, ISO9001
Place of Origin :
Shenzhen, China
MOQ :
1 piece
Price :
Please contact us for latest price
Payment Terms :
T/T,L/C,Credit card,PayPal,D/A,D/P,Western Union,MoneyGram
Supply Ability :
40,000 PCS per day
Delivery Time :
1~7 working days
Packaging Details :
FCL size: 40*30*20cm / Sample Packaging: 20*18*13cm
Screen Size :
2.8 inch
Resolution :
240RGB(H)x320(V)
Brightness (cd/m²) :
300 nit
Interface :
4wire SPI
Driver Ic :
ST7789P3
Display area :
43.20(H)x57.60(V)
Description

TFT Display Description:

This is a 2.8-inch TFT LCD display with IPS technology, offering clear and accurate visuals. Its compact size and versatile functionality make it ideal for various applications, from consumer electronics to industrial equipment.

Parameter:

Model

P028B123P-10-IPS

Screen Size

2.8 inch

Number of Pixel

240RGB(H)x320(V)

Pin

10 pin

Display area

43.20(H)x57.60(V)mm

Pixel pitch

0.180(H)x0.180(V)mm

Outline Dimension

50.00x69.20x2.30mm

Pixel arrangement

RGB Vertical Stripe

Display mode

Normally Black

Viewing Direction(eye)

ALL

Display Color

262K

Luminance(cd/m2)

300 nit

Contrast Ratio

1200:1

Interface

4wire SPI

Back-light

LED Side-light type

Drive IC

ST7789P3

Operation Temperature

-20~70℃

Storage Temperature

-30~80℃
