Polcd 4 Inch RGB 24bit Interface High Brightness 4 Inch TFT LCD Display with 480*800 ST7701S
Polcd 4 Inch RGB 24bit Interface High Brightness 4 Inch TFT LCD Display with 480*800 ST7701S
Polcd 4 Inch RGB 24bit Interface High Brightness 4 Inch TFT LCD Display with 480*800 ST7701S
Polcd 4 Inch RGB 24bit Interface High Brightness 4 Inch TFT LCD Display with 480*800 ST7701S
Polcd 4 Inch RGB 24bit Interface High Brightness 4 Inch TFT LCD Display with 480*800 ST7701S
Polcd 4 Inch RGB 24bit Interface High Brightness 4 Inch TFT LCD Display with 480*800 ST7701S
Polcd 4 Inch RGB 24bit Interface High Brightness 4 Inch TFT LCD Display with 480*800 ST7701S
Polcd 4 Inch RGB 24bit Interface High Brightness 4 Inch TFT LCD Display with 480*800 ST7701S
Specifications
Brand Name :
Polcd
Model Number :
P040HR015-IPS
Certification :
RoHS, ISO9001
Place of Origin :
Shenzhen, China
MOQ :
1 piece
Price :
Please contact us for latest price
Payment Terms :
T/T,L/C,Credit card,PayPal,MoneyGram,Western Union,D/P,D/A
Supply Ability :
40,000 PCS per day
Delivery Time :
1-7 working days
Packaging Details :
FCL size: 40*30*20cm / Sample Packaging: 20*18*13cm
Size (inch) :
4 inch 480x800
Brightness (cd/m²) :
350 nit
Interface :
RGB 24bit
Driver IC :
ST7701S
PIN :
40 pin
Viewing Direction(eye) :
IPS Full View Angle
Contrast Ratio :
1200:1
Display area :
51.84(H)x86.4(V)mm
Description

Parameter:

Model P040HR015-IPS
Screen Size 4 inch
Number of Pixel 480RGB(H)x800(V)
Pin 40 pin
Display area 51.84(H)x86.4(V)mm
Pixel pitch 0.108(H)x0.108(V)mm
Outline Dimension 57.14x95.7x2.1mm
Pixel arrangement RGB Vertical Stripe
Display mode Normally Black
Viewing Direction(eye) ALL
Display Color 262K
Luminance(cd/m2) 350 nit
Contrast Ratio 1200:1
Interface RGB 24bit
Back-light LED Side-light type
LCM IC ST7701S
Operation Temperature -20~70℃
Storage Temperature -30~80℃
