SMC Type VF3130 Pneumatic Directional Control Valve DC24V AC110V AC220V
SMC Type VF3130 Pneumatic Directional Control Valve DC24V AC110V AC220V
SMC Type VF3130 Pneumatic Directional Control Valve DC24V AC110V AC220V
SMC Type VF3130 Pneumatic Directional Control Valve DC24V AC110V AC220V
Specifications
Payment Terms :
T/T,Western Union,MoneyGram
Valve Type :
5 Way 2 Position
Body Material :
Aluminum Alloy
Max Pressure Resistance :
1.2 MPa
Model Number :
VF3130
Voltage :
12VDC, 24VDC, 24VAC, 110VAC, 220VAC
MOQ :
1 pc
Delivery Time :
Negotiation
Wiring Form :
Lead Wire Or DIN43650 Connector
Price :
Negotiation
Pressure Range :
0.15 To 0.8MPa
Certification :
None
Place of Origin :
CHINA
Supply Ability :
100000 pcs per month
Port Size :
In=Out=1/4'', Exhaust=1/8''
Brand Name :
BRANDO
Packaging Details :
Inner Box,Carton,Pallet
Description

SMC Type VF3130 Pneumatic Directional Control Valve DC24V AC110V AC220V


VF3130 is an SMC VF3000-series 5-port pilot-operated solenoid valve, configured as a 2-position single-solenoid valve. It is designed for directional control of pneumatic cylinders and actuators. SMC's current catalog identifies VF3130 as a VF3000 body-ported, single-solenoid configuration.


Working Principle

VF3130 is a 5-port directional control valve. The five ports are used for supply, two actuator ports and exhaust paths.

When the solenoid is energized, the pilot stage shifts the main spool, changing the compressed-air path between the supply, cylinder and exhaust ports. When the electrical signal is removed, the single-solenoid valve returns to its normal position.

This configuration is commonly used for single-control directional switching of pneumatic cylinders.


Typical Applications

VF3130 is suitable for:

Pneumatic cylinder control
Factory automation
Assembly machinery
Packaging equipment
Material-handling equipment
Pick-and-place systems
Pneumatic actuator sequencing


Technial Data of VF & VZ Series Pneumatic Solenoid Valves:

Model
VF3130
VF33(4/5)30
VF5120
VF53(4/5)50
VZ5120
VZ53(4/5)50
VF3230
VF5220
VZ5220
Valve Type
5/2 way
5/3 way
5/2 way
5/3 way
5/2 way
5/3 way
Orifice Size
16mm²
(Cv=0.89)
12mm²
(Cv=0.67)
25mm²
(Cv=1.4)
18mm²
(Cv=1)
12mm²
(Cv=0.67)
9mm² (Cv=0.50)
Fluid
Air (to be filtered by 40 μm filter element)
Operating Pressure
0.15 to 0.8 MPa
Proof Pressure
1.2 MPa
Body
Material
Aluminum Alloy
Max
Frequency
5 cycle / sec
Voltage
12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Wire Form
Lead Wire or DIN43650 Connector


Dimension of VF3130 Pneumatic Solenoid Valve:

SMC Type VF3130 Pneumatic Directional Control Valve DC24V AC110V AC220V
